Greenlee / A Textron Company 9 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
881 and 881CT Cam Track
®
Hydraulic Benders
17. 90° of bend.
16. 60° of bend.
Assembly and Operation Instructions
881 and 881CT—Floor Operation (cont’d)
15. 45° of bend.
20. The 90° bend is complete.
19. Remove the saddle pin.
18. Release the hydraulic pressure. The ram will retract.
