Greenlee 1813 - 1813 Bending Table Components

Greenlee / A Textron Company 10 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
881 and 881CT Cam Track
®
Hydraulic Benders
Identification—Major Components
881 and 881CT Cam Track
®
Hydraulic Bender and 1813 Bending Table
RAM POSITIONER (33) PIPE VISE UNIT (38) LEG SUPPORT UNIT (23)
LEG (25)
PUMP TABLE SUPPORT (26)
BENDER MOUNTING UNIT (27)
PIPE CLAMP (34)
SADDLE
FOLLOW BAR
SHOE
E
E
E
YOKE (B)
YOKE PIN (G)
RAM (A)
SPRING CLIP (H)
ROLLER UNIT (D)
HITCH PIN CLIPS (E)
CYLINDER BLOCK PIN UNIT (F)
CONNECTING BAR UNIT (C)
SADDLE PIN UNIT (M)
