Greenlee Quick Draw 7804SB - Capacity and Draw Stud Guide

Quick Draw
®
Hydraulic Punch Drivers
Greenlee Textron / Subsidiary of Textron Inc. 6 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815/397-7070
Capacity and Draw Stud Selection Guide
31872
3/4" Draw Stud
1614SS
3/8" Draw Stud
1924AA
Spacer
33967
Adapter
1924AA
Spacer
29451
7/16" Draw Stud
1924AA
Spacer
31872
3/4" Draw Stud
1/2"
con.
ø 0.885"
15.2 mm
3/4"
con.
ø 1.115"
28.3 mm
1-7/32" 1"
con.
ø 1.362"
34.6 mm
1-1/4"
con.
ø 1.701"
43.2 mm
1-1/2"
con.
ø 1.951"
49.6 mm
2"
con.
ø 2.416"
61.5 mm
1/2"
con.
ø 0.885"
15.2 mm
3/4"
con.
ø 1.115"
28.3 mm
1-7/32" 1"
con.
ø 1.362"
34.6 mm
1-1/4"
con.
ø 1.701"
43.2 mm
Electronic Connector Punches
RS-232, 229, 231, 234, 238
Standard and Slug-Buster
®
Punches Slug-Splitter
®
Punches
Draw Studs
and Accessories
10 ga. (0.1345" [3.4 mm])
Mild Steel
10 ga. (0.1345" [3.4 mm])
Stainless Steel
16 ga. (0.0598" [1.5 mm])
Mild Steel and 1/8" Soft Aluminum
33967
Adapter
1924AA
Spacer
