13. APPENDIX B: List of errors displayed by Hybrid monitor
IG ERROR LISTING
IG Error listing (HEX field):
Error Name
HEX
Code
DEC
Code
IG response
Reason
Remedy
Note
No error
0x0000
0
/
/
/
DC-link
overvoltage
0x0001
01
Error mode
DC-link voltage
is above 270 V
Wait for DC-link
voltage drop
1
Power
module
warm
0x0002
02
Power reduction
IG IGBT module
temperature is above 85°C
Reduce load /
Check HCU
cooling
Power
module
hot
0x0004
03
Increased power
reduction
IG IGBT module
temperature
is above 90°C
Reduce load /
HCU cooling
required
Power
module
excessive
hot
0x0008
04
Error mode
IG IGBT module
temperature
is above 95°C
Stop / HCU
cooling required
Step up
undervoltage
0x0010
05
Electric propulsion
interrupted
Battery voltage dropped
below 42 V
Recharge battery
Bad power
module
0x0020
06
Only error flag signalization
IG IGBT module
temp. sensor failed
Check / replace
IGBT
CAN lost
0x0040
07
Permanent error mode
CAN Communication
with AC part interrupted
Check / replace
HCU
2
Battery
overvoltage
0x0080
08
Error mode
Battery voltage is
above 61 V
Check battery
