GREENLINE 33 - STEERING SYSTEM

Greenline 33 85
STEERING
1 Rudder stock
Tiller arm
Steering pump
2
3
4
5
Steering piston
Rudder bearing
3
1
2
4
5
Section view A-A
Section view B-B
Scale 2:1
A B B A
Figure 37: Steering system
Regularly check the tightness of steering system components.
Regularly lubricate all the elements.
Maintain the nylon, ertalon or Teflon bushes only with suitable lubricants.
