AC ERROR LISTING
AC Error 1 listing (HEX field):
Error Name
HEX
Code
DEC
Code
AC response
Reason
Remedy
Note
No error
0x0000
0
/
/
/
IG part lost
0x0001
01
Permanent
error mode
CAN communication
with IG part interrupted
Check / replace
HCU
1
Actuator
fail
0x0002
02
Permanent
error mode
Clutch signals have the same
logic state for more than 6 s
Check clutch signals
Cont. high
ph. current
0x0004
03
Permanent power
reduction
Phase current continuously
above max level
Stop / Check load
3
Cont. high
bat. current
0x0008
04
Permanent power
reduction
Calculated battery current
continuously above max level
Stop / Check load
3
Hall failure
0x0010
05
Error mode
Hall sensor malfunction
Check / replace hall
sensors assembly
Motor
temp. max
0x0020
06
Error mode
Measured motor temperature
above 120°C
Stop, electric motor
cooling required
HCU
temp. max
0x0040
07
Error mode
HCU temperature
above 95°C
Stop, HCU cooling
required
Battery
voltage
max
0x0080
08
Error mode
Battery voltage
above 58 V
Check battery
DC_link
over
voltage
0x0100
09
Error mode
DC-link voltage
above 270 V
Wait for DC-link
voltage drop
4
Invalid HCU
command
0x0200
10
Error mode
Wrong state of HCU
command inputs
Check HCU
inputs wiring
Battery
temp. max
0x0400
11
Error mode
Battery temperature
above 55°C
Check battery and
temp. sensor
5
Motor
0x0800
12
Error mode
Measured motor temperature
Check / replace hall
sensors assembly
