Greenline 33 98
temp. min
below -10°C
Battery
temp. min
0x1000
13
Error mode
Battery temperature
below -20°C
Check battery and
temp. sensor
5
Short-
circuit in
Gen. mode
0x2000
14
Error mode
Potential short-circuit
detected during generator
mode
Check HCU power
terminals
ECU part
lost
0x4000
15
Permanent
error mode
CAN communication
with ECU part interrupted
Check ECU
1,2
/
0x8000
16
/
/
/
Note 1: Error decimal code numbers 1 and 2 can occur due to:
• AC part HW or SW failure,
• IG part HW or SW failure,
• bad CAN BUS wiring of both controllers inside HCU,
• electromagnetic noise inside HCU.
Note 2: Error decimal code number 2 can occur due to:
• ECU stops to send PGN0 message
• bad CAN BUS wiring of external devices (PC, DDI, etc.),
• external electromagnetic noise.
Note 3: Exact limit value depends on current HCU operating mode.
Note 4: Error decimal code number 9 shall not be apprehend as an error, if battery voltage is between 53,4 V
and 53,7 V when HCU operates in generator mode (this is usual HCU behaviour when battery is overcharged).
Note 5: Error decimal code numbers 11 and 13 can not occur due to the absence of the battery temperature
measurement. The battery temperature is fixed to 20°C in the current HCU software.
