Greenline 33 49
8. ELECTRICAL SYSTEM
ARRIVING ON THE BOAT
When arriving on the boat you should switch the main switches ON (except for the parallel switch; (Pic.1). If
you are planning to stay docked in the marina or at anchor (A.), it is not necessary to switch ON the propulsion
switches, you can switch them ON before departure (B.)
STAYING AT DOCK OR ANCHOR
A + B. GETTING READY TO SAIL-12 V SERVICE
battery switch (Pic. 1)
-48V HYBRID/HOUSE battery switch (Pic. 2)
-24h CONSUMERS switches (Pic.4)
-INVERTER ON: supplies 230V (Pic.5)
-12 V ENGINE battery switch (Pic. 1)
-48V HYBRID DRIVE switch (Pic. 2)
-BOW THRUSTER switch in front cabin (Pic. 3)
Picture 1: ENGINE and SERVICE main switch
ENGINE and SERVICE main switch. Leave the PARALLEL switch OFF.
