8.2 INSTALL THE NOZZLE
20
19



WARNING
Before you change the nozzle:
1. Pull the gun trigger (10) to release water pressure.
2. Lock the trigger safety button (14) on the gun.
3. Stop the mahcine.
WARNING
Do not point the spray wand (8) at your face or others'.
1. Pull back the quick-connect collar on the spray wand (8).
2. Install the nozzle (19) onto the spray wand (8).
3. Release the quick-connect collar to attach the nozzle (19).
8.2.1 NOZZLE TYPE
SPRAY TIP APPLICATION
25
O
Green - Narrow fan tip (25° )
• The green pressure washer tip pro-
vides high versatility with its 25 de-
gree angle tip. Referred to as the
washing tip, because it provides ade-
quate pressure to remove dirt from
surfaces, but is designed to not dam-
age many surfaces. This pressure
washer tip is designed for “sweep-
ing” foliage or debris given its wide
angle. This tip is versatile due to its
wide area of cleaning and strong
pressure application.
SPRAY TIP APPLICATION
40
O
White - Wide fan tip (40° )
• The white 40 degree tip, referred to
as the “fan” tip creates the widest
area of cleaning with relatively low
pressure. This pressure washer tip is
best used for light or delicate clean-
ing applications. It is recommended
for light cleaning on wood decks and
other soft or delicate surfaces.
8.3 INSTALL THE DETERGENT TANK
21
9
WARNING
Do not use household detergents, acids, alkalines, bleaches,
solvents, flammable material, or industrial grade solutions,
which can do damage to the pump.
WARNING
Do the instructions on the solution bottle to prepare
detergent.
NOTE
If it is necessary, use a funnel to prevent the spill of
detergent. Clean and dry the spilled detergent when you fill
it.
1. Put the detergent into the detergent tank (21).
2. Install the detergent tank onto the gun (9).
3. Turn counter-clockwise the gun (9) to tighten.
NOTE
Do not let detergent dry on the surface to prevent streaks.
