3.2 UNPACK THE MACHINE
WARNING
Make sure that you correctly assemble the machine before
use.
WARNING
• If the parts are damaged, do not use the machine.
• If you do not have all the parts, do not operate the
machine.
• If the parts are damaged or missing, speak to the service
center.
1. Open the package.
2. Read the documentation in the box.
3. Remove all the unassembled parts from the box.
4. Remove the machine from the box.
5. Discard the box and package in compliance with local
regulations.
3.3 INSTALL THE UPPER PANEL
1. Aligh the screw sleeves of the upper panel (10) with the
screw holes on the upper handle.
2. Push the screws through the screw sleeves and tighten
them.
3.4 INSTALL THE HOSE HOOK
1. Push the hose hook (15) ends into the clips behind the
front panel (10) tightly .
3.5 INSTALL THE SPRAY GUN
HOLDER
1. Aligh the screw sleeves of the spray gun holder (17) with
the screw holes on the upper handle.
2. Push the screws through the screw sleeves and tighten
them.
