.5
2 7 ',+,9
Before assembly, remove the battery from the tool.
&+""+,9!7,8!'(:#\+,9!")(!Z7""('O!V&+9L5W
• To insert the battery (1), line it up with the battery compartment (3) on the tool. Slide the
battery into the battery compartment and push until the battery snaps into place.
• To remove the battery, push the release button (2) while at the same time pulling the battery
out of the battery compartment.
2 7 ',+,9
To p re v en t a cc i de nt a l o pe ra t io n , e ns ur e t h at th e b at t er y i s r em o ve d a nd th a t t he sc ab b ar d i s i n
place on the saw chain before performing the following operations. Failure to do this could result in
serious personal injury.
788+,9!Z7'!7,8!U)7+,!$YZ'+U7,"!V&+9L6W
Use a bar and chain lubricant (not included) with this product. It is designed for chains and chain
oilers, and is formulated to perform over a wide temperature range with no dilution required.
• Remove oil cap.
• Carefully pour the bar and chain oil into the tank.
• Wipe off excess oil. Replace oil cap.
• Check and ll the oil tank when quick view oil indicator is below the second to last indicator
line.
• Repeat as needed.
NOTE: This pole saw comes from the factory with no bar and chain oil added. Level should
also be checked after every 20 minutes of use and relled as needed. Do not use dirty, used or
ASSEMBLY
1
&+9L5
2
3
