A B C
Mod.
GF21
1100 780 1300
Mod.
GF27
1200 780 1300
Mod.
GF35
1480 1040 1250
11. MACHINE SIZE
Pict. 5
10. SHIPMENT
This boring machine is packed in a wooden box and/or in a cardboard and nylon box.
Machine handling is possible with:
- fork-lift trucks
- bridge cranes
- pallet trucks
Weight is indicated in paragraph 8.1 and hoisting points can be seen in the picture below. When the ma-
chine is handled it is necessary to make sure that the surrounding area is free from obstacles. If the ma-
chine is stored, it must be kept in a dry place, protected from rain, snow or dampness. During all han-
dling operations, we advise you to pay great attention in order to prevent any damage to people, things
or to the machine itself.
GRIGGIO S.p.A.
WOODWORKING MACHINERY
10
