GRIGGIO GF 21 - TABLE 1 FRAME PARTS

TABLE 1 FRAME
GRIGGIO S.p.A.
WOODWORKING MACHINERY
30
Pos. Code 21G Code 27G Part name Quantity
1 36200084 36200084
Frame Left Side
1
2 36222147 36222147
Clamping Block
1
3 00000117 00000117
D-En M 12
4
4 00018402 00018402
V-Te M 10 X 25
6
5 36222104 36222104
Electrical Box G Version
1
6 36222122 36222122
Clamping Plate
1
7 36222123 36222123
45° Threaded Bush
1
8 00018602 00018602
V-Tbei M 10 X 20
10
9 00000109 00000109
D-Es M 8
1
10 00004047 00004047
Gn 605 Screw M8 X 18 Type A
1
11 49900045 49900045
Supporting Plate
1
12 76200030 76200030
Rod With Clamping Slot Mod G
1
13 36200080 36700080
Patterned Front Cover
1
14 36222119 36222119
Vacuum Plastic Front Cover
1
15 00018421 00018421
V-Tspei M5x10
12
16 36222124 36222124
Clamping Hexagon
1
17 36200082 36200082
Frame Right Side
1
18 00018522 00018522
R-Cild M 10
6
19 36222120 36222120
Block Spacer
1
20 36222121 36222121
45° Stop Pin
1
21 00018523 00018523
R-Cild M 12
1
22 00018403 00018403
V-Te M 12x35
4
23 00015224 00015224
Flow Control G1-4 Pnmx Cod6.01.14n
1
24 00003947 00003947
Release Lever Krp-100 M12x60
1
25 00018501 00018501
D-En M 8
2
26 36222117 36222117
Plate Version G
1
27 00015223 00015223
Cover Lever D30 Pnmx Cod228.32.5-2-3vie
1
28 36200086 36700086
Table Back Cross Beam
1
29 36000087 36000087
Air Unit Plate
1
30 00000017 00000017
Galvan. Steel Washer Uni-6592, Ø Nom. Mm 5
4
31 00018297 00018297
Galvanised Tcbei-Screw M5x12
4
32 00018531 00018531
Deb M 4
2
33 00018290 00018290
Vcce-5931 M 4 X 12
2
34 00003104 00003104
Boteco 732-25 M8x16
1
35 0003303 0003303
Seeger Ring E 15
2
36 36222118 36222118
Clamping Unclamping Plate Version G
1
37 OPTIONAL OPTIONAL
Drill Holder
1
38 36222105 36222105
Control Board Sheet
1
39 00018521 00018521
R-Cild M 8
2
40 00018307 00018307
Vcce-5931 M 8x16
2
41 36222116 36222116
Overturning Plate Version G
1
