GRIGGIO GF 21 - TABLE 2 MACHINE TABLE PARTS

TABLE 2 MACHINE TABLE
Pos. Code 21G Code 27G Part name Quantity
1 36222017 36722017
Table
1
2 36222019 36722019
Millimetrical scale
1
3 0003924 0003924
Release lever 563-65 M8 L16
1
4 36000021 36000021
Central spline
1
5 36000022 36000022
45° plate
1
6 36000112 36000112
Rotation pin
1
7 36001016 36001016
Bronze shimming ring
2
8 00004238 00004238
p-st 8 x 16 casehardened
4
9 00018521 00018521
r-cild M 8
5
10 00005045 00005045
plain bearing PAP 2530P10
2
11 49900017 49900017
pin spring
1
12 00005103 00005103
self-tapping screw 3.9x9.5 galvanised 6955
6
13 36222126 36222126
index disk
1
14 45400052 45400052
Degree plate
1
15 00150909 00150909
G-EICO M 8x20
6
16 49900014 49900014
Reference Pin
1
17 49900015 49900015
Reference Pin block
1
18 00003923 00003923
Boteco ball knob Art. 100-20 M5
1
19 00004303 00004303
Elastic pin Ø 4x14 6873
1
20 49900016 49900016
Reference Pin square
1
21 00018405 00018405
V-te M 8x16
4
22 36222125 36222125
Hollow rotation pin
1
23 00018302 00018302
Round-headed screw M6x10
1
GRIGGIO S.p.A.
WOODWORKING MACHINERY
32
