GRIGGIO GF 21 - TABLE 8 HOLD DOWN CLAMPS PARTS

TABLE 8 HOLD DOWN CLAMPS
GRIGGIO S.p.A.
WOODWORKING MACHINERY
44
Pos. Code 21G Code 27G Part name Quantity
1 00003120 00003120
Boteco 119-32 M6
1
2 49970047 49970047
Wedge-shaped piston
1
3 49970048 49970048
Threaded cylinder
1
4 00000118 00000118
Nut M14-basso-5589
1
5 49970146 49970146
Piston spring
1
6 49970045 49970045
Clamping ring nut
1
7 49900089 49900089
Head pipe
1
8 49900088 49900088
Sliding head
1
9 499700133 499700133
Spacing hold down clamp
1
10 49970042 49970042
Piston cylinder cover
1
11 49970135 49970135
Shaft protection
1
12 49970043 49970043
Piston shaft
1
13 49970049 49970049
Upper head
1
14 49900095 49900095
Nylon bumper
1
15 49970051 49970051
Lower head
1
16 00001120 00001120
Piston gasket
1
17 00001121 00001121
Or Pneumax Cod R-1502.50.5
1
18 49970040 49970040
Piston cylinder
1
19 49970041 49970041
Hollow screw M 10
1
20 00003393 00003393
Seeger ring 50
1
21 49970052 49970052
Piston
1
22 49970053 49970053
Piston spring
1
23 00018420 00018420
VSCE-5933 M4x12
1
24 00120404 00120404
G-ipp M 4x4
1
25 00005103 00005103
Self-tapping screw 3.9x9.5 galvanised 6955
1
