Grizzly DEEP DIGGER - Roller - 7 Tyne Deep Digger

36
Specications are subject to change without prior notication From serial number 7027
DESCRIPTIONPART NO.QTYITEM
GE50 RADIAL SPHERICAL
PLAIN
BDGAA0012
1
HOUSING 2 BOLT SB TYPEBZGCA00222
BEARING 1-1/2" Eccentric
Locking Collar - Wide Series
BZJEA05623
DEPTH GAUGE CABSE132
14
BEARING HOUSING - 3
BOLT
CDEUU00025
BOLT M 8 X 25FABEA02546
BOLT M12 X 65 PC 8.8FABGA06527
BOLT M12 X 120 PC 10.9FABGA120
4
8
BOLT M20 X 80 pc 8.8
COARSE
FABJA08069
NYLOC NUT M8 P TYPEFFBEA000410
NYLOC NUT M12 P TYPEFFBGA000611
NYLOC NUT M20 P TYPE
2.5
FFBJA000612
INTERNAL CIRCLIP 75 FKDWA003213
FLAT WASHER 30mm / 1
1/4" HD 33X55X4
FMAUKP02214
M8 WASHER 5/16"F436
HARD ZYP
FMCEE000415
M12 WASHER 1/2" type
1HARD ZYP
FMCGE000416
DEPTH GAUGE POINTERGNBEN005
117
DEPTH GAUGE POINTERGNBEN006118
ROLLER BRKT. 7 TYNE
DEEP DIGGER
GNBRM003119
ROLLER DRUM 7 TYNE
DEEP DIGGER
GNBRM004120
HOLLOW BAR 56 X 40
(30mm)
MFHGA030221
GREASE EVERY 10 HRS
DECAL
PD000GR10222
GREASE EVERY 40 HRS
DECAL
PD000GR40223
ROLLER - 7 TYNE DEEP DIGGER (3759
OVERALL)
L:\Inventor\Parts\GD-\GDNRJ007.idw
19
14
9
5
1
13
12
17
7
4
6
15
10
8
3
21
16
11
GDNRJ007
20
