Grizzly DEEP DIGGER - Page 41

41
Specications are subject to change without prior notication December 2019
DESCRIPTIONPART NOQTYPOS
GE50 RADIAL SPHERICAL PLAINBDGAA00121
PLATE 50mm BEARING HOUSINGCDEUU000
22
ROLLER POINTERGNBEN00013
M16 WASHER 5/8" F436 HARD ZYPFMCHE00084
INTERNAL CIRCLIP 75
FKDWA00325
NYLOC NUT M20 P TYPE 2.5FFBJA00066
NUT NYLOC M16 P TYPE PC8 ZINCFFBHA00047
NYLOC NUT M12 P TYPEFFBGA00028
BOLT M20 X 80 pc 8.8 COARSEFABJA08069
BOLT M12 X 65 PC 8.8FABGA065
210
GREASE NIPPLE 1/8 BSP BMCAA000211
ROLLER / 11 TYNE DEEP DIGGAGNBRM016112
ROLLER BRACKET 11 TYNE DEEP DIGGERGNBRM015
113
HOUSING 214 PILLOW BLOCKBZJEA07C214
BEARING EW214 (EW214DH) 70mmBZGCA070215
BOLT M 16 X 160 pc 8.8 zinc
FABHA160416
ROLLER ASSEMBLY 11 TYNE
L:\Inventor\Parts\GD-\GDNRJ011H.idw
9
2
1
5
6
3
8
10
13
12
4
16
15
14
11
GDNRJ011H
