Grizzly DEEP DIGGER - Page 42

42
Specications are subject to change without prior notication From serial number 7027
DESCRIPTIONPART NOQTYPOS
GE50 RADIAL SPHERICAL PLAINBDGAA00121
GREASE NIPPLE 1/8 BSP BMCAA000
22
BEARING EW214 (EW214DH)
70mm
BZGCA07023
HOUSING 214 PILLOW BLOCKBZJEA07C
24
DEPTH GAUGE CABSE13015
PLATE 50mm BEARING HOUSINGCDEUU00026
BOLT M 8 X 25FABEA0254
7
BOLT M12 X 75 PC 8.8FABGA07528
BOLT M 16 X 160 pc 8.8 zinc
FABHA16049
BOLT M20 X 80 pc 8.8 COARSEFABJA080610
NYLOC NUT M8 P TYPEFFBEA000411
NYLOC NUT M12 P TYPEFFBGA000
212
NUT NYLOC M16 P TYPE PC8
ZINC
FFBHA000413
NYLOC NUT M20 P TYPE 2.5
FFBJA000614
NYLOC NUT M30 P TYPEFFBNA000215
INTERNAL CIRCLIP 75 FKDWA003216
30mm FLAT WASHER HD ZINC
33X55X4
FMAUKP02217
M8 WASHER 5/16"F436 HARD ZYPFMCEE000418
M12 WASHER 1/2" type 1HARD
ZYP
FMCGE000219
M16 WASHER 5/8" F436 HARD ZYPFMCHE000
820
DEPTH GAUGE POINTERGNBEN005121
WIDE ROLLER-11 TYNE DEEP
DIGGER 6.5M
GNBRM016-A122
ROLLER BRACKET 11 TYNE
DEEP DIGGER- 6.5
GNBRM11545123
HYDRAULIC KIT (ROLLER) 11 CTFGNBRN004124
GREASE EXERY 10 HRS DECALPD000GR10225
GREASE EXERY 40 HRS DECALPD000GR40226
ROLLER ASSY 11 TYNE CTF
L:\Inventor\Parts\GD-\GDNRJ11545.idw
22
3
4
9
20
10
1
6
16
14
23
12
8
GDNRJ11545
