-72-
Model G0602/G0752 (Mfg. Since 11/12)
READ ELECTRICAL SAFETY
ON PAGE 66!
G0752 Control Panel Components
Figure 107. Control panel.
Figure 108. RPM display.
Figure 111. Right junction box.
Figure 109. Variable speed potentiometer.
Figure 110. Spindle speed circuit board.
Figure 112. Spindle speed sensor.
E-Stop
Button
Switch
ON Button
Switch
OFF
Button
Switch
Spindle
Direction
Switch
