Grizzly G0602 User Manual

Model G0602/G0752 (Mfg. Since 11/12)
-85-
REF PART # DESCRIPTION REF PART # DESCRIPTION
801 P0602801 PLUG 826 P0602826 COLLAR
802 P0602802 O-RING 827 PK132M KEY 4 X 4 X10
803 P0602803 BUSHING 828 P0602828 GEAR SHAFT
804 P0602804 CLUSTER GEAR 30/36/33T 829 P0602829 GEAR 33T
805 PK133M KEY 4 X 4 X 50 830 P0602830 GEAR 30T
806 P0602806 GEAR SHAFT 831 P0602831 GEAR 35T
807 P0602807 BUSHING 832 P0602832 FLANGE
808 P0602808 CLUSTER GEAR 22/44/33T 833 PCAP01M CAP SCREW M6-1 X 16
809 P0602809 CLUSTER GEAR PLUG 834 P0602834 SHIFT FORK
810 PCAP50M CAP SCREW M5-.8 X 10 835 P0602835 FRONT GEARBOX COVER
811 P0602811 REAR GEARBOX COVER 836 PRP05M ROLL PIN 5 X 30
812 P0602812 FILL PLUG 3/8" NPT 837 P0602837 COMPRESSION SPRING
813 P0602813 GEAR BOX CASE 838 P0602838 SIGHT GLASS A16
814 P0602814 DRAIN PLUG 3/8" NPT 839 P0602839 POINTER DISC
815 P0602815 SHEAR PIN 5 X 20 840 PSS01M SET SCREW M6-1 X 10
816 P0602816 LEADSCREW CONNECTING COLLAR 841 PSTB004M STEEL BALL 5MM
817 P0602817 SHEAR PIN 5 X 20 842 P0602842 SHIFT HUB
818 PCAP26M CAP SCREW M6-1 X 12 843 PSS01M SET SCREW M6-1 X 10
819 P0602819 FLANGE 844 PCAP37M CAP SCREW M6-1 X 50
820 P6202-OPEN BALL BEARING 6202-OPEN 845 PCAP02M CAP SCREW M6-1 X 20
821 P0602821 GEAR 33T 846 P0602846 O-RING 1.8 X 6.7
822 PR05M EXT RETAINING RING 15MM 847 P0602847 SHAFT
823 PK65M KEY 4 X 4 X 8 848 PRP03M ROLL PIN 5 X 20
824 P0602824 GEAR SHAFT 22T 849 P0602849 SHIFT LEVER
825 P0602825 GEAR 44T 850 P0602850 SHIFT FORK
Gearbox Parts List

Grizzly G0602 Specifications

General

Number of Spindle Speeds	6
Motor	1 HP
Voltage	110V
Swing Over Bed	10 inches
Spindle Bore	1 inch
Spindle Speed	70-2000 RPM
