G0612 6" Jointer
After all the parts have been removed from the
box, you should have the following items:
Jointer Box Contents: (Figure
4 & 5)
Qty
A. Jointer Bed Assembly ................................ 1
B. Fence ......................................................... 1
C. Dust Collection Bag .................................... 1
D. Push Blocks ................................................ 2
E. Fence Tilting Handle .................................. 1
F. Fence Bracket Assembly ........................... 1
G. Fence Sliding Handle ................................. 1
H. Locking Plate Assembly ............................. 1
I. Fence Support ............................................ 1
J. Dust Chute ................................................. 1
K. Dust Collection Bag Clamp ........................ 1
Hardware
(Not Shown) ................................. Qty
• Cap Screws M8-1.25 x 20 ..........................
6
• Lock Washers 8mm ...................................
6
• Hex Wrench 4mm ......................................
1
• Hex Wrench 6mm ......................................
1
• Pan Head Screw M6-1 x 25 .......................
1
Figure 4
.
Box contents 1.
Figure 5
.
Box contents 2.
K
J
Inventory
I
In the event that any nonproprietary parts are
missing (e.g. a nut or a washer), we would be
glad to replace them, or for the sake of expedi
-
ency, replacements can be obtained at your local
hardware store.
NOTICE
Some assembly fasteners may arrive pre-
installed on the machine. Check the mount
-
ing locations on the machine before assum
-
ing that any items from the inventory list are
missing.
A
B
C
F
D
E
G
H
