Depth-of-Cut
Elevation Crank
Figure 14
Note: Any time you switch directions with the
cutterhead elevation crank, there will be a small
amount of backlash—so the first turn of the crank
after switching directions will be slightly less than
1
⁄16". However, as long as you move the crank in
the same direction during operation, backlash will
not be a factor.
&
¿)Ijgc
2
&
¿+)
&
¿'Ijgc
2
&
¿('
(
¿)Ijgc
2
(
¿+)
&Ijgc
2
&
¿&+
9dlcJe
Figure 14. Crank elevation increments.
Depth-of-Cut Gauge
To use the depth-of-cut gauge:
1.
Figure 15
2.
3.
Note:The depth-of-cut gauge should only be
used for approximate measurements. If pre-
cise workpiece thicknesses are needed, use
calipers to ensure your workpieces meet your
standards.
Note:Sliding the gauge cover to the "Open"
position disables the gauge.
Figure 15.
.
