G0703/G0703P 110V Wiring Diagram
Motor 110V
1
2
3
4
Run
Capacitor
40MFD
250VAC
Start
Capacitor
300MFD
125VAC
Power
Switch
Circuit
Breaker/
Thermal
Overload
Circuit
Board 110V
L2
L1
COM
M2
M1
GND
Hot
Neutral
Ground
110 VAC
G
W
Neutral
Hot
Ground
110 VAC
5-20 Plug
(As Recommended, With Inlet Restrictor)
L5-30 Plug
(As Recommended,
Without Inlet Restrictor)
