Grizzly g0703 User Manual

Model G0703/G0703P (Mfg. Since 3/12)
-47-
REF PART # DESCRIPTION REF PART # DESCRIPTION
1V2 P0703001V2 MOTOR 1-1/2 HP 110/220V 1PH V2.01.12 37 P0703037 LOWER COLLECTION DRUM
1V2-1 P0703001V2-1 MOTOR FAN COVER 38 P0703038 DRUM SUCTION PIPE
1V2-2 P0703001V2-2 MOTOR FAN 38-1 P0703038-1 DRUM SUCTION PIPE SEAL
1V2-3 P0703001V2-3 REMOTE RECEIVER BOX 39 P0440056 CASTER 2"
1V2-4 P0703001V2-4 S CAPACITOR 300M 125V 1-1/2 X 3-1/8 40 PLW04 LOCK WASHER 3/8
1V2-5 PC040F R CAPACITOR 40M 250V 1-3/8 X 2-3/8 41 PN08 HEX NUT 3/8-16
1V2-6 P0703001V2-6 CIRCUIT BOARD 110V 256 CODE 42 PW02 FLAT WASHER 3/8
1V2-7 P0703001V2-7 THERMAL OVERLOAD TRANKEY 25A 43 P0703043 PADDLE CRANK
1V2-8 P0703001V2-8 REMOTE CONTROL PANEL 44 P0703044 ROTATION HANDLE
1V2-9 P0703001V2-9 POWER SWITCH 45 PLN01 LOCK NUT 3/8-16
1V2-10 PN07 HEX NUT 10-24 46 PW02 FLAT WASHER 3/8
1V2-11 PW03 FLAT WASHER #10 47 PB07 HEX BOLT 5/16-18 X 3/4
1V2-12 PS06 PHLP HD SCR 10-24 X 3/8 49 PR09M EXT RETAINING RING 20MM
1V2-14 P0703001V2-14 REMOTE CONTROLLER 256 CODE 51 P0703051 SEAL
1V2-15 PLW01M LOCK WASHER 5MM 52 P0703052 PADDLE SHAFT
1V2-17 P0703001V2-17 PHLP HD SCR M5-.8 X 15 COPPER 53 P0703053 PADDLE BRACKET
1V2-18 P0703001V2-18 HEX NUT M5-.8 COPPER 54 P0703054 PADDLE
1V2-20 P0703001V2-20 TERMINAL NUT SW-74BH 55 PB02 HEX BOLT 1/4-20 X 5/8
1V2-21 P0703001V2-21 STRAIN RELIEF MG-20 56 PW06 FLAT WASHER 1/4
1V2-22 P0703001V2-22 CONTACT PLATE 57 PLN02 LOCK NUT 1/4-20
1V2-23 P0703001V2-23 CENTRIFUGAL SWITCH 3450 58V2 P0703058V2 CANISTER FILTER 386 X 534MM V2.3.11
1V2-24 P0703001V2-24 FRONT MOTOR BEARING 58V2-1 P0703058V2-1 CANISTER FILTER SEAL V2.3.11
1V2-25 P0703001V2-25 REAR MOTOR BEARING 62 PB07 HEX BOLT 5/16-18 X 3/4
2 P0703002 MOTOR GASKET 64V2 P0703064V2 BAG CLAMP 390MM V2.3.11
3 PTLW02 EXT TOOTH WASHER 5/16 65 P0703065 PLASTIC BAG 400 X 600MM
4 PB07 HEX BOLT 5/16-18 X 3/4 66V2 P0703066V2 UPPER FRAME V2.03.12
5 P0703005 MOTOR MOUNTING PLATE 67 PCAP30 CAP SCREW 5/16-18 X 1/2
6 PW07 FLAT WASHER 5/16 68 PW07 FLAT WASHER 5/16
7V2 PB32 HEX BOLT 5/16-18 X 5/8 69 P0703069 FRAME HANDLE
8 P0703008 IMPELLER 13-1/2" 70 PB07 HEX BOLT 5/16-18 X 3/4
9 P0703009 BLOWER HOUSING 71 PW07 FLAT WASHER 5/16
10 P0703010 INTAKE CYLINDER 7" 79 P0703079 FRAME BRACE
10-1 P0703010-1 INTAKE CYLINDER SEAL 80 PB07 HEX BOLT 5/16-18 X 3/4
12 PB09 HEX BOLT 5/16-18 X 1/2 81 PW07 FLAT WASHER 5/16
13V2 P0703013V2 INTAKE BARREL 9-13/16" X 16-1/2" 82 P0703082 LOWER FRAME
13-1 P0703013-1 INTAKE BARREL SEAL 83 P0703083 FRAME END CAP
20 P0703020 DUST HOSE CLEAR 7" X 7" 84 P0440056 CASTER 2"
21 P0440026 HOSE CLAMP 7" 85 P0703085 PLASTIC BAG 510 X 1070MM
22 P0703022 FUNNEL SUCTION PIPE 86 P0703086 DUST HOSE GREY 1" X 6-1/2'
22-1 P0703022-1 FUNNEL SUCTION PIPE SEAL 86-1 P0703086-1 PLASTIC HOSE PLUG 1"
23V2 PB09 HEX BOLT 5/16-18 X 1/2 87 P0703087 HOSE CLAMP 1"
24 PW07 FLAT WASHER 5/16 88V2 P0703P088 CIRCUIT BOARD 220V 256 CODE V2.01.12
25V2 P0703025V2 COLLECTION DRUM LID 7" V2.3.11 89 P0443014 IMPELLER FENDER WASHER 5/16
26 P0703026 COLLECTION DRUM SEAL 90 PB31 HEX BOLT 1/4-20 X 1
27 P0703027 LATCH HOOK 91 PHTEK39M TAP SCREW M4 X 12
28 P0703028 RIVET 92 P0703092 INLET RESTRICTOR 5" X 6"
29 P0703029 UPPER COLLECTION DRUM 93 P0703093 COPPER PHLP HD SCR M5-.8 X 12
30 P0440053 DRUM LID LATCH 94 PTLW02M EXT TOOTH WASHER 5MM
31 PS06 PHLP HD SCR 10-24 X 3/8 95 P0703095 GROUND WIRE
32 PN07 HEX NUT 10-24 96 P0703096 COPPER HEX NUT M5-.8
33 P0703033 DRUM CLAMP 98v2 P0703098V2 FILTER CAGE, BEIGE V2.07.12
34 PB04 HEX BOLT 5/16-18 X 3 98-1 P0703098-1 CANISTER FILTER CAGE SEAL
35 PN02 HEX NUT 5/16-18 99 P0703099 POWER CORD 12G 3W 36"
36 P0703036 VACUUM SUCTION PLATE
G0703 Parts List
