Model G0703/G0703P (Mfg. Since 3/12)
-49-
G0703P Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0703P001 MOTOR 1-1/2 HP 110/220V 1PH V1 36 P0703036 VACUUM SUCTION PLATE
1-1 P0703P001-1 MOTOR FAN COVER 37 P0703P037 LOWER COLLECTION DRUM
1-2 P0703P001-2 MOTOR FAN 38 P0703038 DRUM SUCTION PIPE
1-3 P0703P001-3 REMOTE RECEIVER BOX 38-1 P0703038-1 DRUM SUCTION PIPE SEAL
1-4 P0703P001-4 S CAPACITOR 300M 125V 1-1/2 X 3-1/8 39 P0440056 CASTER 2"
1-5 PC040F R CAPACITOR 40M 250V 1-3/8 X 2-3/8 40 PLW04 LOCK WASHER 3/8
1-6 P0703P001-6 CIRCUIT BOARD 110V 256 CODE 41 PN08 HEX NUT 3/8-16
1-7 P0703P001-7 THERMAL OVERLOAD TRANKEY 25A 42 PW02 FLAT WASHER 3/8
1-8 P0703P001-8 REMOTE CONTROL PANEL 43 P0703P043 PADDLE CRANK
1-9 P0703P001-9 POWER SWITCH V1 44 P0703044 ROTATION HANDLE
1-10 PN07 HEX NUT 10-24 45 PLN01 LOCK NUT 3/8-16
1-11 PW03 FLAT WASHER #10 46 PW02 FLAT WASHER 3/8
1-12 PS06 PHLP HD SCR 10-24 X 3/8 47 PB07 HEX BOLT 5/16-18 X 3/4
1-13 P0703P001-13 POWER CORD 12AWG 3C 10FT 48 PW07 FLAT WASHER 5/16
1-14 P0703P001-14 REMOTE CONTROLLER 256 CODE 49 PR09M EXT RETAINING RING 20MM
1-15 P0703P001-15 LOCK WASHER 5MM 50 P0703050 PADDLE SHAFT CAP
1-17 P0703P001-17 PHLP HD SCR M5-.8 X 15 COPPER 51 P0703051 SEAL
1-18 P0703P001-18 HEX NUT M5-.8 COPPER 52 P0703052 PADDLE SHAFT
1-19 P0703P001-19 PHLP HD SCR 10-24 X 3/8 53 P0703053 PADDLE BRACKET
1-20 P0703P001-20 TERMINAL NUT SW-74BH 54 P0703054 PADDLE
1-21 P0703P001-21 STRAIN RELIEF MG-20 55 PB02 HEX BOLT 1/4-20 X 5/8
1-22 P0703P001-22 CONTACT PLATE 56 PW06 FLAT WASHER 1/4
1-23 P0703P001-23 CENTRIFUGAL SWITCH 3450 57 PLN02 LOCK NUT 1/4-20
1-24 P0703P001-24 FRONT MOTOR BEARING 58 P0703P058 CANISTER FILTER 386 X 534MM
1-25 P0703P001-25 REAR MOTOR BEARING 58-1 P0703P058-1 CANISTER FILTER SEAL
2 P0703002 MOTOR GASKET 61 PW07 FLAT WASHER 5/16
3 PW07 FLAT WASHER 5/16 62 PB07 HEX BOLT 5/16-18 X 3/4
4 PB32 HEX BOLT 5/16-18 X 5/8 64 P0440033 BAG CLAMP 400MM
5 P0703P005 MOTOR MOUNTING PLATE 65 P0440034 PLASTIC BAG 400 X 600MM
6 PW07 FLAT WASHER 5/16 66 P0703P066 UPPER FRAME
7 PB32 HEX BOLT 5/16-18 X 5/8 67 PCAP30 CAP SCREW 5/16-18 X 1/2
8 P0703008 IMPELLER 13-1/2" 68 PW07 FLAT WASHER 5/16
9 P0703P009 BLOWER HOUSING 69 P0703P069 FRAME HANDLE
10 P0703010 INTAKE CYLINDER 7" 70 PB07 HEX BOLT 5/16-18 X 3/4
10-1 P0703010-1 INTAKE CYLINDER SEAL 71 PW07 FLAT WASHER 5/16
11 PW07 FLAT WASHER 5/16 79 P0703P079 FRAME BRACE
12 PB09 HEX BOLT 5/16-18 X 1/2 80 PB07 HEX BOLT 5/16-18 X 3/4
13 P0703P013 CYCLONE FUNNEL ASSEMBLY 81 PW07 FLAT WASHER 5/16
13-1 P0703013-1 CYCLONE FUNNEL SEAL 82 P0703P082 LOWER FRAME
15 PB32 HEX BOLT 5/16-18 X 5/8 83 P0703083 FRAME END CAP
17 PB07 HEX BOLT 5/16-18 X 3/4 84 P0440056 CASTER 2"
20 P0703020 DUST HOSE CLEAR 7" X 7" 85 P0703085 PLASTIC BAG 510 X 1070MM
21 P0440026 HOSE CLAMP 7" 86 P0703086 DUST HOSE GREY 1" X 6-1/2'
22 P0703022 FUNNEL SUCTION PIPE 86-1 P0703086-1 1" PLASTIC HOSE PLUG
22-1 P0703022-1 FUNNEL SUCTION PIPE SEAL 87 P0703087 HOSE CLAMP 1"
23 PB09 HEX BOLT 5/16-18 X 1/2 88 P0703P088 CIRCUIT BOARD 220V 256 CODE
24 PLW01 LOCK WASHER 5/16 89 P0443014 MOTOR FENDER WASHER 5/16
25 P0703P025 COLLECTION DRUM LID 9" 90 PB31 HEX BOLT 1/4-20 X 1
26 P0703026 COLLECTION DRUM SEAL 91 PHTEK39M TAP SCREW M4 X 12
27 P0703027 LATCH HOOK 92 P0703092 INLET RESTRICTOR 5" X 6"
28 P0703028 RIVET 93 P0703093 COPPER PHLP HD SCR M5-.8 X 12
29 P0703P029 UPPER COLLECTION DRUM 94 PLW01M LOCK WASHER 5MM
30 P0440053 DRUM LID LATCH 95 P0703095 GROUND WIRE
31 PS06 PHLP HD SCR 10-24 X 3/8 96 P0703096 COPPER HEX NUT M5-.8
32 PN07 HEX NUT 10-24 98 P0703P098 CANISTER FILTER CAGE
33 P0703033 DRUM CLAMP 98-1 P0703P098-1 CANISTER FILTER CAGE SEAL
34 PB04 HEX BOLT 5/16-18 X 3 99 P0703099 POWER CORD 12G 3W 36"
35 PN02 HEX NUT 5/16-18
