-6-
Model G0857/G0858 (Mfd. Since 07/19)
The information contained herein is deemed accurate as of 9/18/2018 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.
PAGE 1 OF 3
Model G0857
MACHINE DATA
SHEET
Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
MODEL G0857 8" X 76" PARALLELOGRAM JOINTER WITH
MOBILE BASE
Product Dimensions:
Weight.............................................................................................................................................................. 365 lbs.
Width (side-to-side) x Depth (front-to-back) x Height..................................................................... 76 x 25 x 41-1/2 in.
Footprint (Length x Width)............................................................................................................................ 40 x 16 in.
Shipping Dimensions:
Type.......................................................................................................................................................... Wood Crate
Content........................................................................................................................................................... Machine
Weight.............................................................................................................................................................. 470 lbs.
Length x Width x Height....................................................................................................................... 85 x 26 x 43 in.
Must Ship Upright................................................................................................................................................... Yes
Electrical:
Power Requirement........................................................................................................... 230V, Single-Phase, 60 Hz
Motor Size............................................................................................................................................................ 3 HP
Full-Load Current Rating........................................................................................................................................ 12A
Minimum Circuit Size.............................................................................................................................................. 20A
Connection Type....................................................................................................................................... Cord & Plug
Power Cord Included.............................................................................................................................................. Yes
Power Cord Length................................................................................................................................................. 6 ft.
Power Cord Gauge......................................................................................................................................... 14 AWG
Plug Included.......................................................................................................................................................... Yes
Included Plug Type................................................................................................................................................ 6-20
Switch Type....................................................................................... Push Button Magnetic w/Large Shut-Off Paddle
Motors:
Main
Horsepower................................................................................................................................................ 3 HP
Phase............................................................................................................................................ Single-Phase
Amps............................................................................................................................................................ 12A
Speed................................................................................................................................................ 3450 RPM
Type................................................................................................................. TEFC Capacitor-Start Induction
Power Transfer .................................................................................................................................. Belt Drive
Bearings........................................................................................................ Sealed & Permanently Lubricated
Centrifugal Switch/Contacts Type......................................................................................................... External
Main Specifications:
Main Specifications
Jointer Size.................................................................................................................................................. 8 in.
Bevel Jointing............................................................................................................................. 0 – 45 deg. L/R
Maximum Width of Cut................................................................................................................................ 8 in.
Maximum Depth of Cut............................................................................................................................. 1/8 in.
Minimum Workpiece Length...................................................................................................................... 10 in.
Minimum Workpiece Thickness................................................................................................................ 1/2 in.
Maximum Rabbeting Depth...................................................................................................................... 1/2 in.
Number of Cuts Per Minute..................................................................................................................... 22,000
Machine Data Sheet (G0857)
