-88-
Model G0899 (Mfd. Since 10/20)
BUY PARTS ONLINE AT GRIZZLY.COM!
Scan QR code to visit our Parts Store.
Labels & Cosmetics
WARNING!
EYE/LUNG INJURY
HAZARD!
Always wear safety
glasses and a
respirator when
using this machine
Rotating blade adjustment handwheels into
stopping positions with excessive force could
result in a loss of blade parallelism with miter
slot, impaired stop-collar accuracy, and
damage to internal components. This type of
damage is not covered by warranty!
INJURY HAZARD!
Do not open door
while machine is
connected to power
or blade is in motion.
Industrial Rip Fence
For Your Own Safety Read
Instruction Manual Before
Operating Saw
a) Wear eye protection.
b) Use saw-blade guard
and spreader for every
operation for which it can
be used, including all
through sawing.
c) Keep hand out of the
line of saw blade.
d) Use a push-stick when
required.
e) Pay particular attention
to instructions on
reducing risk of kickback.
f) Do not perform any
operation freehand.
g) Never reach around or
over saw blade.
Debris on front rail can
misalign fence and increase
risk of kickback.
Reduce this risk by
cleaning front rail before
positioning fence.
Do not expose to rain or use in damp
locations.
AVERTISSEMENT!: Ne pas exposer à la
pluie et ne pas utiliser dans les
emplacements humides.
No exponga a la lluvia ni la utilice en lugares
húmedos.
If connected to a circuit protected by fuses, use a
time-delay fuse marked “D”.
Si cette machine est connectée à un circuit protégé
par des fusibles, employer des fusibles à action
différée marqués «D».
Si està conectado a un circuito protegido por
fusibles, use un fusible de retardo temporal
marcado "D".
Specifications
WARNING!
MODEL G0899
10" HYBRID TABLE SAW w/RIVING KNIFE
12. Make sure blade is stopped before adjusting the height or tilt.
13. Do not perform any operation freehand.
14. Never use fence and miter gauge at the same time.
15. Ensure machine is stable and fence is parallel with blade.
16. Disconnect power before changing blades or servicing saw.
17. Plan cuts so that workpieces always remain supported.
18. Non-through cuts (i.e. dadoes, rabbets, moulding cuts) and
resawing cuts present specific dangers; refer to the manual.
19. Do not wear loose clothing, gloves, jewelry, or other items that
can get entangled. Tie back long hair and roll up sleeves.
20. Do not expose to rain or operate in a wet environment.
21. Prevent unauthorized use by children or untrained users;
restrict access or disable machine when unattended.
To reduce risk of serious injury when using this machine:
1. Read and understand owner’s manual before operating.
2. Never touch moving blade, and keep hands out of cutting path.
3. Always wear approved eye protection and respirator.
4. Only plug power cord into a grounded outlet.
5. Always use blade guard/spreader for all through cuts; and use
riving knife for all non-through cuts. If a certain cut cannot be
made with either device, some other safeguard MUST be used.
6. Only use blades meeting size/speed requirements for this saw.
7. Ensure spreader/riving knife and fence are properly adjusted.
8. Never reach behind or over blade while it is moving.
9. Use a push stick when required and whenever possible,
especially with small/narrow workpieces and non-through cuts.
10. Know what causes “kickback” and how to prevent it.
11. Never remove jammed/cutoff workpiece when blade is moving!
Motor: 2 HP, 115V/230V, 60 Hz, Single-Phase
Pre-Wired: 115V
Full-Load Current Rating: 16A at 115V, 8A at 230V
Blade Size: 10" x 5/8" Arbor
Required Blade Kerf Thickness: 0.102" – 0.126"
Arbor Speed: 4000 RPM
Max. Rip Capacity: 31-1/2"
Max. Depth of Cut @ 90˚: 3-1/8"
Max. Depth of Cut @ 45˚: 2-1/8"
Max. Dado Width: 13/16"
Weight: 403 lbs.
Date
SN
Mfd. for Grizzly in Taiwan
177335
701V2
To reduce risk of death
or serious injury, read
manual BEFORE using
machine.
To get a new manual,
call (800) 523-4777 or
go to www.grizzly.com.
WARNING!
702
703
The Model G0899
spreader/riving knife is
0.1" thick. Follow these
requirements to ensure the
spreader/riving knife works
safely:
BLADE REQUIREMENTS
Standard Blades
• Diameter: 10"
• Max. Body Thickness: 0.094"
• Min. Kerf Thickness: 0.102"
• Must be aligned with
spreader or riving knife.
Dado Blades
• Dado blades under 10"
diameter not compatible
with riving knife.
• Max Width: 13/16"
704
INJURY/SHOCK
HAZARD!
Disconnect power
before adjustments,
maintenance, or
service.
705
706
709
710
711
712
713
G0899
715
717V2
718
Removing blade
guard increases
risk of injury—it
MUST be installed
when possible.
If blade guard is
removed for a
special cut, some
other safeguard
MUST be used.
AMPUTATION
HAZARD!
Always keep
fingers and
hands away from
moving blade.
Disconnect power
before changing
blades or blade
guard and riving
knife.
716
Safety labels help reduce the risk of serious injury caused by machine hazards. If any label comes
off or becomes unreadable, the owner of this machine MUST replace it in the original location
before resuming operations. For replacements, contact (800) 523-4777 or www.grizzly.com.
REF PART # DESCRIPTION REF PART # DESCRIPTION
701V2 P0899701V2 MACHINE ID LABEL V2.10.20 710 P0899710 TOUCH-UP PAI NT, GRIZZLY BEI GE
702 P0899702 READ MANUAL LABEL 711 P0899711 EYE/LUNG HAZARD LABEL - SMALL
703 P0899703 TABLE SAW WARNING LABEL 712 P0899712 GRIZZLY NAMEPLATE
704 P0899704 RIVING KNIFE CAUTION LABEL 713 P0899713 GRIZZLY GREEN TAPE
705 P0899705 DISCONNECT POWER LABEL 715 P0899715 MODEL NUMBER LABEL
706 P0899706 ELECTRICITY LABEL 716 P0899716 GRIZZLY.COM LABEL
707 P0899707 DO NOT OPEN DOOR WARNING LABEL 717V2 P0899717V2 FENCE LABEL V2.01.20
708 P0899708 BLADE GUARD LABEL 718 P0899718 DO NOT EXPOSE TO RAIN LABEL
709 P0899709 HANDWHEEL NOTICE LABEL
