Grizzly G1026 Parts List

G1026 3 H.P. Shaper -E-
REF PART # DESCRIPTION
101 P1026101 HANDLE
102 P1026102 HANDWHEEL
103 PSS17 SETSCREW
5
⁄16"-18 x
5
⁄16"
105 P1026105 SLEEVE
107 PB07 HEX BOLT
5
⁄16"-18 x
3
⁄4"
108 P1026108 SHAFT MOUNT
111 P1026111 WORM SHAFT
112 P1026112 GIB
113 PN02 HEX NUT
5
⁄16"-18
114 PSS14 SETSCREW
5
⁄16"-18 x 1
3
⁄8"
115 P1026115 ELEVATION HOUSING
116 PB56 HEX BOLT
1
⁄2"-13 x 1
3
⁄4"
117 PW01 FLAT WASHER
1
⁄2"
120 P1026120 POINTER
123 P1026123 POINTER MOUNT
126 PB19 HEX BOLT
1
⁄4"-20 x
1
⁄2"
128 P1026128 LOCK KNOB
130 PLN07 LOCK NUT
5
⁄8"-11
133 P1026133 GEAR
REF PART # DESCRIPTION
133A
P1026133A THRUST BEARING 51103
135 PK14M KEY 5 x 5 x 18
136 P1026136 ELEVATION LEAD SCREW
139 PRP24M ROLL PIN 5 x 16
140 PB16 HEX BOLT
1
⁄2"-13 x 1
3
⁄8"
141 PLW04 LOCK WASHER
3
⁄8"
142 PW07 FLAT WASHER
5
⁄16"
143 PLW01 LOCK WASHER
5
⁄16"
145 PSS23 SETSCREW
5
⁄16"-24 x
5
⁄8"
146 P1026146 V-BELT M7 x 690
147 P1026147 MOTOR PULLEY
148 PB03 HEX BOLT
5
⁄16"-18 x 1"
149 PB56 HEX BOLT
1
⁄2"-13 x 1
3
⁄4"
151 P1026151 MOTOR MOUNT PLATE
152 P1026152 3H.P. MOTOR
153 PK15M KEY 5 x 5 x 35
154 PB09 HEX BOLT
5
⁄16"-18 x
1
⁄2"
155 PW14 FLAT WASHER
5
⁄8"
156 PW06 FLAT WASHER
1
⁄4"
