Grizzly G1028 User Manual

-12- G1028/G1029 Dust Collector
Figure 8.
Flex Hose
Slip a loosened hose clamp over each end of the
flex-hose and slide one end of the flex-hose over
the outlet flange. Slide the other end of the flex-
hose onto the collector. Tighten each hose clamp
until snug. Figure 8.
Figure 10.
Bag
1. Hook the top loop of the filter bag over the
support bracket. Figure 9.
2. Slip the collection bag over the top edge of
the collector and pull the strap tight to
secure. Figure 9.
Figure 9.

Grizzly G1028 Specifications

General

Brand	Grizzly
Model	G1028
Category	Dust Collector
Language	English
