Grizzly G1035 Parts List

G1035 Heavy-Duty Shaper
-C-
23 PW07 FLAT WASHER
5
⁄16"
24 P1035024 FENCE ADJ. SCREW
25 PSS03 SETSCREW
1
⁄4" - 20 x
3
⁄8"
26 P1035026 FENCE MOUNT RIGHT
27 PN02 HEX NUT
5
⁄16"- 18
28 PW07 FLAT WASHER
5
⁄16"
29 P1035029 WOOD FACING
30 PFH07 FLT HD SCRW
5
⁄16" - 18 x 1
1
⁄4"
31A
P1035031A
SWITCH BOX
32 PSW03 FWD⁄REV SWITCH
33A
P1035033A
SWITCH BOX COVER
33B PFS04M FLANGE SCREW M4-.7 X 6
34 P1035034 MOUNT BRACKET
35 P1035035 MOTOR CORD, 5 WIRE
36 P1035036 POWER CORD, 3 WIRE
37 P1071075 STRAIN RELIEF
38A PN07 HEX NUT 10-24
39 PHTEK1 SELF TAPPING SCREW
40 P1026041 SCALE
41 P1035041 NAMEPLATE LABEL
41A P1035041A
WARNING LABEL
42 P1035042 GROMMET
45 PTLW01 EXT TOOTH WASHER #10
01 P1035001 STAND
02 P1035002 MOTOR COVER
03 PS06 PHLP HD SCRW 10-24 x
3
⁄8"
04 PB21 HEX BOLT
3
⁄8" - 16 x
3
⁄4"
05 PLW04 LOCK WASHER
3
⁄8"
06 PW02 FLAT WASHER
3
⁄8"
07 P1035007 TABLE
08 P1035008 TABLE INSERT
09 P1035009 TABLE INSERT
10 P1035010 BARREL SCREW
11A PFH21 FLAT HD SCRW 10-24 x
3
⁄4"
12 P1035012 STARTING PIN
13A P1026046 LOCK HANDLE
5
⁄16"- 18 x 1"
14 PW07 FLAT WASHER
5
⁄16"
15 P1035015 FENCE MOUNT, LEFT
16 PLW04 LOCK WASHER
3
⁄8"
17 PSB16 CAP SCREW
3
⁄8" - 16 x
3
⁄4"
18 PSB07 CAP SCREW
5
⁄16" - 18 x
3
⁄4"
19 P1035019 MAIN FENCE HOUSING
20A PSS05 SETSCREW
5
⁄16" - 18 x
1
⁄4"
21 P1035021 KNURLED KNOB
22 P1035022 ADJ. SCREW BRACKET
REF PART # DESCRIPTION
REF PART # DESCRIPTION
