Grizzly G1071 Instruction Manual

- 21 -
G1071 Oscillating Spindle Sander
082 PLW04 LOCK WASHER
3
/8"
083 PSS07 SETSCREW
1
/
4" - 20 x
1
/
2"
084 PRP42M ROLL PIN 3 x 20mm
085 PW02 FLAT WASHER
3
/8"
086 PN02 HEX NUT
5
/16" - 18
087 PSB38 CAP SCREW 10 - 32 x
3
/8
"
088 PB16 HEX BOLT
3
/8" - 16 x 1
1
/2"
089 PN08 HEX NUT
3
/8
" - 16
090 PSB03 CAP SCREW
5
/16" - 18 x 1"
091 PLW01 LOCK WASHER
5
/16"
092 PSB16 CAP SCREW
3
/8
" - 16 x
3
/4
"
093 PSB16 CAP SCREW
3
/8" - 16 x
3
/4"
094 P6206 BEARING 6206 - 2RS
095 P1071095 SEAL 30 - 62 - 8
096 PR38M SNAP RING 62mm
097 P6205 BEARING 6205 - 2RS
098 PSB39 CAP SCREW 5 - 40 x
1
/2"
099 PRP05M ROLL PIN 5 x 30mm
100 PK12M KEY 5 x 5 x 30mm
101 PSS08 SETSCREW
5
/
16" - 18 x
1
/
2"
102 P1126153 DRAIN PLUG
103 PN04 HEX NUT
5
/8" - 11
104 PLW06 LOCK WASHER
5
/8"
105 PB19 HEX BOLT
1
/4" - 20 x
1
/2"
106 PLW02 LOCK WASHER
1
/4"
107 PB03 HEX BOLT
5
/16" - 18 x 1"
108 P1071108
5
/
16" FENDER WASHER
109 PN13 HEX NUT
1
/2
" - 13
110 PSS29 SETSCREW 10 - 24 x
1
/4"
111 PN03 HEX NUT
3
/4" - 16
112 PS03 PHLP HD SCRW 10 - 24 x 1"
113 PN07 HEX NUT 10-24
114 P1071114 SPEC CAP SCRW
5
/16" - 18 x 1"
115 PW02 FLAT WASHER
3
/8"
116 P1071116 SPACER
117 P1071117 NAME PLATE
118 P1071118 INSERT 4
1
/
8"
119 P1071119 DUST COVER
121 PK22M KEY 5 x 5 x 24mm
122 P1071122 STEEL INSERT 1
1
⁄2 - 4
123 P1071123 MOUNTING PLATE
REF# PART# DESCRIPTION REF# PART# DESCRIPTION
PARTS LIST
