Power Feed Parts List, continued

REF PART # DESCRIPTION REF PART # DESCRIPTION

511-1 P3616511-1 LIFTFORK 515-2 P3616515-2 RAPID SWITCH HOUSING

511-2 P3616511-2 LIFTFORK RING 515-3 P3616515-3 SPRING FOR RAPID SWITCH

511-3 P3616511-3 PIN, LIFTFORK RING 3 X 14 515-4 PEC13M E-CLIP 5MM

512-1 P3616512-1 X CONTROL HANDLE ASSY 516 P3616516 CIRCUIT BOARD ASSEMBLY

512-2 P3616512-2 Y,Z CONTROL HANDLE ASSY 517 P3616517 CIRCUIT BOARD INSULATOR

512-3 P3616512-3 HANDLE KNOB M8-1.25 518 P3616518 TRAVEL STOP ASSEMBLY

512-4 PSS04M SET SCREW M6-1 X 12 518-1 P3616518-1 TRAVEL STOP

512-5 P3616512-5 CONTROL HANDLE 518-2 P3616518-2 TRAVEL STOP BASE

513 P3616513 ZYTEL GEAR ASSEMBLY 518-3 P3616518-3 TRAVEL STOP SHAFT

513-1 P3616513-1 ZYTEL GEAR WITHOUT HUB 518-4 P3616518-4 SPRING

513-2 PW21M FLAT WASHER 32MM 518-5 PB07M HEX BOLT M8-1.25 X 25

513-3 P3616513-3 HUB OF ZYTEL GEAR 518-6 P3616518-6 SPACER

513-4 P3616513-4 LOCK WASHER 38MM 518-7 PR39M EXT RETAINING RING 8MM

513-5 PR29M INT RETAINING RING 32MM 519 P3616519 SPEED CONTROL KNOB ASSEMBLY

514-1 P3616514-1 POTENTIOMETER ASSEMBLY 519-1 P3616519-1 SPEED CONTROL KNOB M6-1

514-2 P3616514-2 POTENTIOMETER RING 519-2 P3616519-2 SPEED CONTROL LABEL

514-3 P3616514-3 POTENTIOMETER SARAIN 519-3 PSS49M SET SCREW M4-.7 X 16

514-4 PW05M FLAT WASHER 4MM 512-1-1 P3616512-1-1 X CONTROL HANDLE DISC

514-5 PS17M PHLP HD SCR M4-.7 X 6 512-1-2 P3616512-1-2 Y,Z CONTROL HANDLE DISC

515 P3616515 RAPID SWITCH BUTTON 514-1-1 PN03M HEX NUT M8-1.25

515-1 P3616515-1 RAPID SWITCH PLUNGER 514-1-2 P3616514-1-2 POTENTIOMETER WASHER
