Grizzly G3616 Parts Breakdown

52 G3616/G3617 Mill
Column Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P3616001 BASE 48 P3616048 WIPER PLATE
2 P3616002 COLUMN (G3616) 49 P3616049 WIPER PLATE
2 P3617002 COLUMN (G3617) 50 P3616050 WIPER PLATE
3 P3616003 ELEVATING SCREW HOUSING 51 P3616051 KNEE
4 PLW06M LOCK WASHER 10MM 52 P3616052 CLAMP BLOCK
5 PB116M HEX BOLT M10-1.5 x 45 53 P3616053 CLAMP BOLT M10-1.5 x 58 X 25
6 P3616006 CONNECT TUBE 54 P3616054 HOIST DESCEND LEAD SCREW
7 PS38M PHLP HD SCR M4-.7 x 10 55 P3616055 CIRCULAR NUT
8 PB131M HEX BOLT M16-2 X 65 56 P3616056 CONICAL GEAR
9 PLW10M LOCK WASHER 16MM 57 PK95M KEY 6 X 6 X 10
10 P3616010 COLLAR 58 P3616058 BALL BEARING 25 X 42 X 11
11 PSB31M CAP SCREW M8-1.25 x 25 59 P3616059 ADJUST WASHER
12 P3616012 HOLD SUPPORT 60 P3616060 COLLAR
13 PSB77M CAP SCREW M12-1.75 X 30 61 P3616061 BALL BEARING 25 X 42 X 11
14 P3616014 AROUND BRACKET 62 P3616062 HEX NUT DIA. 42 X 60MM
15 P3616015 FEED SHAFT 63 PSS16M SET SCREW M8-1.25 X 10
16 P3616016 COLLAR 64 PK09M KEY 8 X 8 X 36
17 P3617017 CLAMP BOLT M12-1.75 X 58 X 25 65 P3616065 CONICAL GEAR
18 P3616018 CLAMP BLOCK 66 PK34M KEY 5 X 5 X 20
19 P3616019 GIB 67 PW19M FLAT WASHER 42 x 25 x 3MM
20 PFH42M FLAT HD SCR M8-1.25 x 40 68 P3616068 COLLAR
21 P3616021 OVERARM 69 PSS80M SET SCREW M8-1.25 x 15
22 P3616022 COVER 70 P3616070 SHAFT
23 PS08M PHLP HD SCR M5-.8 X 12 71 P3616071 COLLAR
24 P3616024 COVER 72 PSB114M CAP SCREW M6-1 x 22
25 PS08M PHLP HD SCR M5-.8 X 12 73 P3616073 BALL BEARING 25 X 42 X 11
26 P3616026 HOLD BRACKET 74 P3616074 SCALE RING
27 P3616027 GEAR 75 P3617075 KNURLED THUMB SCR M6-1 X 10
28 PSB122M CAP SCREW M16-2 X 50 76 P3616076 COLLAR
29 PSB123M CAP SCREW M16-2 X 60 77 P3616077 HANDLE
30 P3616030 NOZZLE 78 P3617078 LIFT BAR (G3617)
31 P3616031 OIL CUP 79 P3617079 TOOLHOLDER (G3617)
32 PSB01M CAP SCREW M6-1 x 16 80 P3617080 CUTTER BAR COLLAR (G3617)
33 PSB01M CAP SCREW M6-1 x 16 81 P3617081 SUPPORT (G3617)
34 P3616034 CONNECT TUBE 82 P3617082 SPECIAL BOLT M16-2 X 218 (G3617)
35 P3616035 HOLD BRACKET 83 P3617083 COLLAR (G3617)
36 PN13M HEX NUT M16-2 84 P3617084 SPECIAL NUT M22 X 1.5MM (G3617)
37 PLW10M LOCK WASHER 16MM 85 PSS06M SET SCREW M8-1.25 x 16 (G3617)
38 P3616038 T BOLT M16-2 X 63 86 P3617086 OIL CUP (G3617)
39 PS08M PHLP HD SCR M5-.8 X 12 87 PW08M FLAT WASHER 16MM (G3617)
40 P3616040 ELECTRIC PUMP 88 PN13M HEX NUT M16-2 (G3617)
41 PB83M HEX BOLT M6-1 X 16 89 P3617089 BEHIND COVER (G3617)
42 P3616042 SUPPORT 90 P3617090 HINGE (G3617)
43 P3616043 DUST COVER 91 PFH25M FLAT HD SCR M4-.7 X 12 (G3617)
44 PS08M PHLP HD SCR M5-.8 X 12 92 PS96M PHLP HD SCR M10-1.5 x 8 (G3617)
45 P3616045 GIB 93 P3616093 VERTICAL SPINDLE SPEEDS LABEL
46 P3616046 ADJUST SCREW M8-1.25 94 P3617094 HORZ SPINDLE SPEEDS LABEL
47 PS08M PHLP HD SCR M5-.8 X 12 95 G8588 GRIZZLY CAST IRON LOGO PLATE
