Grizzly G3616 Parts Breakdown

58 G3616/G3617 Mill
G3617 Horizontal Spindle Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
303 PSB31M CAP SCREW M8-1.25 x 25 343 PN13M HEX NUT M16-2
304 P3617304 OIL CUP 344 PW08M FLAT WASHER 16MM
305 P3617305 COVER 345 PW08M FLAT WASHER 16MM
306 P3617306 SPINDLE 346 P3617346 SMALL SHAFT
307 P3617307 BALL BEARING 55 X 90 X 23 347 P3617347 CONNECT
308 P3617308 COLLAR 349 P6003 BALL BEARING 6003ZZ
309 P3617309 BALL BEARING 40 X 90 X 25 350 P3617350 COLLAR
310 P3617310 SPECIAL WASHER 52 X 4 351 P6003 BALL BEARING 6003ZZ
311 P3617311 FLAT WASHER 39MM 352 PR18M EXT RETAINING RING 17MM
312 P3617312 SLOTTED LOCK NUT M39 X 1.5MM 353 PR21M INT RETAINING RING 35MM
313 P3617313 COVER 354 P3617354 PULLEY
314 PSB31M CAP SCREW M8-1.25 x 25 355 PVA31 V-BELT A-31 4L310
315 P3617315 OIL CUP 356 P3617356 ADJUST SCREW M8-1.25
316 P3617316 SPINDLE PULLEY 357 P3617357 SUPPORT
317 PK90M KEY 10 X 10 X 25 358 PSB02M CAP SCREW M6-1 x 20
318 PR12M EXT RETAINING RING 35MM 359 P3617359 SPECIAL NUT M8-1.25
319 PVA30 V-BELT A-30 4L300 360 P3617360 MOTOR
320 PK42M KEY 6 X 6 X 30 360-1 P3617360-1 MOTOR FAN COVER
321 PR09M EXT RETAINING RING 20MM 360-2 P3617360-2 MOTOR FAN
322 P3617322 WHEEL 360-3 P3617360-3 R CAPACITOR COVER
323 P6003 BALL BEARING 6003ZZ 360-4 PC020B R CAPACITOR 20MFD 450VAC
324 P3617324 BEARING 37MM 360-5 P3617360-5 S CAPACITOR COVER
325 P6003 BALL BEARING 6003ZZ 360-6 PC150A S CAPACITOR 150MFD 250VAC
326 P3617326 COLLAR 360-7 P3617360-7 WIRING BOX
328 P3617328 SMALL SHAFT 361 PLW04M LOCK WASHER 8MM
329 P3617329 COLLAR 362 PB07M HEX BOLT M8-1.25 x 25
330 P3617330 SUPPORT 363 P3617363 MOTOR WHEEL
331 PSB02M CAP SCREW M6-1 x 20 364 PSS04M SET SCREW M6-1 X 12
332 PB13M HEX BOLT M10-1.5 x 80 365 PK43M KEY 8 X 8 X 45
333 PN02M HEX NUT M10-1.5 366 PVA31 V-BELT A-31 4L310
334 PR25M INT RETAINING RING 47MM 385 P3617385 1" HORIZONTAL ARBOR
335 PR11M EXT RETAINING RING 25MM 385-1 P3617385-1 1" ARBOR NUT
336 P3617336 SPECIAL NUT M64 X 2 385-2 P3617385-2 1" ARBOR SLEEVE
337 PR25M INT RETAINING RING 47MM 385-3 P3617385-3 1" ARBOR SPACER
338 P3617338 PULLEY 386 P3617386 1-1/4" HORIZONTAL ARBOR
339 PR11M EXT RETAINING RING 25MM 386-1 P3617386-1 1-1/4" ARBOR NUT
340 P3617340 KEY 8 X 8 X 50 386-2 P3617386-2 1-1/4" ARBOR SLEEVE
341 P3617341 MOTOR BASE 386-3 P3617386-3 1-1/4" ARBOR SPACER
342 PSB124M CAP SCREW M12-1.75 X 80
