-22- G5979 Wood Lathe
Customer Service #: (570) 546-9663 • To Order Call: (800) 523-4777 • Fax #: (800) 438-5901
MACHINE DATA
SHEET
Design Type ....................................................................................................Bench Model
Overall Dimensions:
Height ......................................................................................................................44''
Length ......................................................................................................................60''
Shipping Weight ...............................................................................................190 lbs.
Box Size ..................................................................................54
1
⁄2" L x 13" W x 14" H
Footprint ..................................................................................................43
1
⁄2" x 18
1
⁄2"
Construction:
Bed ................................................................................................Cast Iron Flat Ways
Headstock........................................................................................................Cast Iron
Specifications:
Inboard Spindle Size, Type ........................................................................1'' x 8 T.P.I.
Tailstock ..............................................................................................................MT #2
Spindle ................................................................................................................MT #2
Range Of Speeds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 @ 580 - 2850 R.P.M.
Swing ........................................................................................................................12''
Distance Between Centers ....................................................................................35
1
⁄2''
Swing Over Tool Rest . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 ' '
Swivel Head ..............................................................................Stops @ 90° and 180°
Motor:
Type ............................................................................TEFC Capacitor Start Induction
Horsepower ........................................................................................................
1
⁄2 H.P.
Phase ⁄ Cycle ..........................................................................................Single ⁄ 60 Hz
Voltage ..................................................................................................................110V
Amperage..................................................................................................................4A
R.P.M.....................................................................................................................1720
Bearings ..............................................................Sealed and Permanently Lubricated
Accessories:
......................................................................................................................Tool Rest
........................................................................................................Live Rolling Center
..................................................................................................................Spur Center
....................................................................................................................Face Plate
..........................................................................Extension Bed for Out-Board Turning
......................................................................................................Tool Rest Extension
................................................................................................................Paddle Switch
Specifications, while deemed accurate, are not guaranteed.
GRIZZLY MODEL G5979 SWIVEL HEAD WOOD LATHE
