G5979 Wood Lathe -25-
Ref# Part# Description
01 P5979001 HEADSTOCK
02 P5979002 DRIVE CENTER
03 P5979003 DISC
04 P5979004 SPINDLE
05 PK18M KEY 4 X 4 X 82
06A P5979006A BALL BEARING 80205Z
07A P5979007A BALL BEARING 80205Z
008 P5979008 SPRING
09 P5979009 BRACKET—SHIFTING LEVER
10 P6006 BALL BEARING 6006ZZ
11 P5979011 C-RING S-25
12 P5979012 SPINDLE PULLEY SET R & L
13 PVM23 V-BELT M-23 3L230
15 P5979015 C-RING S-24
16 P5979016 PIN-INJECTION
17A PLN09 LOCK NUT M12-1.75
18 P5979018 CLAMP LEFT
19 PB07M HEX BOLT M8-1.25 X 25
20 P5979020 RACK
21 P5979021 GEAR ASSEMBLY
21-1 PS09M PHLP HD SCR M5-.8 X 10
22 P5979022 CLAMP RIGHT
23 P5979023 SPECIAL SCREW
24A P5979024A SHAFT
24-1 P5979024-1 SPRING
24-2 P5979024-2 LOCK HANDLE
24-3 P5979024-3 SPECIAL CAP SCREW
25 P5979025 WRENCH
26 P5979026 C-RING S-16
27 P5979027 SLEEVE
28 P5979028 SPRING
30 P5979030 MOTOR PULLEY SET, L & R
31 PS09M PHLP HD SCR M5-.8 X 10
32 PK18M KEY 4 x 4 x 82
33 P5979033
1
⁄2 H.P. MOTOR
34 P5979034 MOTOR COVER
35 P5979035 ANGULAR SETTING ASSEMBLY
36 P5979036 TOOL REST
37 P5979037 HANDLE ASSEMBLY
38 P5979038 EXTENSION TOOL REST
Ref# Part# Description
39 P5979039 TOOL REST BODY
40 P5979040 ECCENTRIC ROD
41 PR08M EXT RETAINING RING 19MM
42 P5979042 SPECIAL SCREW
43 P5979043 CLAMP
44A P5979044A HEX NUT M18-2.5
45 P5979045 CENTER
46 P5979046 TAIL SPINDLE
47 P5979047 TAILSTOCK SCREW
48 P5979048 TAILSTOCK
48-1 PPSS25M SET SCREW M6-1 X 20
49 P5979049 HANDWHEEL
50 P5979050 LOCK HANDLE-TAILSTOCK
51 P5979051 SPECIAL BOLT
52 P5979052 EXTENSION BED
53 PSB64M CAP SCREW M10-1.5 X 25
53-1 PLW06M LOCK WASHER 10MM
54-1 P5979054-1 STAND LEG, LEFT
54-3 P5979054-3 STAND UPPER COVER
54-4 P5979054-4 STAND LONG-CROSS SUPPORT
54-5 P5979054-5
STAND SHORT-CROSS SUPPORT
54-6 P5979054-6 STAND LEG, RIGHT
55 P5979055 BED
56 PSB11M CAP SCREW M8-1.25 x 16
57A PSW08 SWITCH 110V WITH KEY
58 PS21M PHLP HD SCR M4-.7 X 15
59 P5979059 PLASTIC JAM NUT M20 X 1.5
60 PCB02M CARRIAGE BOLT M8-1.25 x 10
61 PW01M FLAT WASHER 8MM
62 PN03M HEX NUT M8-1.25
63
PWRCRD110L POWER CORD 110V, LONG W/PLUG
64 P5979064 LOGO LABEL
65-1 P5979065-1 GRIZZLY ID/WARNING LABEL
66 P5979066 SPEED LABEL
68 P5979068 SWITCH BOX
69 P5979069 SWITCH FIXING PLATE
71 P5979071 MOTOR POWER WIRE
