G9749 Variable Speed Drill Press
-3-
The information contained herein is deemed accurate as of 3/18/2007 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.
PAGE 1 OF 2Model G9749
MACHINE DATA
SHEET
Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
MODEL G9749 VS DRILL PRESS
Product Dimensions:
Weight.............................................................................................................................................................. 615 lbs.
Length/Width/Height....................................................................................................................... 33-1/8 x 22 x 75 in.
Foot Print (Length/Width)............................................................................................................................. 26 x 19 in.
Shipping Dimensions:
Type............................................................................................................................................Wood Crate/Slats 2 S
Content............................................................................................................................................................ Machine
Weight.............................................................................................................................................................. 776 lbs.
Length/Width/Height............................................................................................................................. 37 x 29 x 72 in.
Electrical:
Switch...........................................................................................................................................................Reversible
Switch Voltage...................................................................................................................................................... 220V
Cord Length............................................................................................................................................................
7 ft.
Cord Gauge....................................................................................................................................................14 gauge
Recommended Breaker Size............................................................................................................................ 20 amp
Plug.........................................................................................................................................................................Yes
Motors:
Main
Type..................................................................................................................
TEFC Capacitor Start Induction
Horsepower...........................................................................................................................................1-1/2 HP
Voltage........................................................................................................................................................
220V
Prewired......................................................................................................................................................220V
Phase........................................................................................................................................................ Single
Amps..........................................................................................................................................................16/8A
Speed.................................................................................................................................................1725 RPM
Cycle..........................................................................................................................................................60 Hz
Number Of Speeds...........................................................................................................................................
1
Power Transfer .........................................................................................................................................V-Belt
Bearings........................................................................................................
Shielded, Permanently Lubricated
Main Specifications:
Construction
Table Construction...............................................................................................................................
Cast Iron
Spindle Housing Construction.............................................................................................................. Cast Iron
Column Construction............................................................................................................... Ground Cast Iron
Head Construction................................................................................................................................Cast Iron
Base Construction................................................................................................................................
Cast Iron
Paint.......................................................................................................................................................... Epoxy
Head Information
Head Swivel.......................................................................................................................................... 360 deg.
