This tool creates a lot of wood chips/
dust during operation. Breathing air-
borne dust on a regular basis can
result in permanent respiratory ill-
ness. Reduce your risk by wearing a
respirator and capturing dust with a
dust-collection system.
Figure 6. Model T32540 dust port.
Model T32540 (Mfd. Since 10/20) -13-
2. Tug hose to make sure it does not
come off.
Note: A tight fit is necessary and
ensures proper performance during
operation.
Dust Collection
To connect to dust collection system:
1. Attach hose from dust collection sys-
tem to dust port (see Figure 6) and
secure with a hose clamp.
— If dust collection hose is larger than
1¼", attach 1"–1
5
⁄
8
" dust collection
adaptor (not included) to dust port,
then attach hose to adaptor.
The Model T32540 is equipped with a 1¼"
dust port that can attach to a dust collec-
tion system or shop vacuum.
Refer to ACCESSORIES on Page 22 for a
1"–1
5
⁄
8
" dust collection adaptor available at
www.grizzly.com.
Dust Port
