Page 1 of 2 Model T32540
MODEL T32540
DUAL-SPINDLE DOWELING JOINTER
Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
Product Dimensions:
Weight ������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 7 lbs�
Width (side-to-side) x Depth (front-to-back) x Height ������������������������������������������������������������������������������ 13-1/2 x 6-1/2 x 9 in�
Shipping Dimensions:
Type ������������������������������������������������������������������������������������������������������������������������������������������������������������������� Cardboard Box
Content �������������������������������������������������������������������������������������������������������������������������������������������������������������������������� Machine
Weight �������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 9 lbs�
Length/Width/Height �������������������������������������������������������������������������������������������������������������������������������������������27 x 17 x 11 in�
Electrical:
Power Requirement ������������������������������������������������������������������������������������������������������������������������ 120V, Single-Phase, 60 Hz
Full-Load Current Rating ����������������������������������������������������������������������������������������������������������������������������������������������������� 5�9A
Minimum Circuit Size ����������������������������������������������������������������������������������������������������������������������������������������������������������� 15A
Connection Type ����������������������������������������������������������������������������������������������������������������������������������������������������� Cord & Plug
Power Cord Included ������������������������������������������������������������������������������������������������������������������������������������������������������������Yes
Power Cord Length ������������������������������������������������������������������������������������������������������������������������������������������������������������79 in�
Power Cord Gauge ������������������������������������������������������������������������������������������������������������������������������������������������������� 18 AWG
Plug Included ������������������������������������������������������������������������������������������������������������������������������������������������������������������������Yes
Included Plug Type ��������������������������������������������������������������������������������������������������������������������������������������������������������������1-15
Switch Type ������������������������������������������������������������������������������������������������������������������������������������������ ON/OFF Toggle Switch
Motor:
Horsepower �������������������������������������������������������������������������������������������������������������������������������������������������������������������������1 HP
Phase �������������������������������������������������������������������������������������������������������������������������������������������������������������������� Single-Phase
Amps ����������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 5�9A
Speed ����������������������������������������������������������������������������������������������������������������������������������������������������������������������17,000 RPM
Type �����������������������������������������������������������������������������������������������������������������������������������������������������������������������������Universal
Power Transfer ����������������������������������������������������������������������������������������������������������������������������������������������������������������� Direct
Bearings ����������������������������������������������������������������������������������������������������������������������������� Shielded & Permanently Lubricated
Main Specifications:
Operation Info
Supported Drill Bit Sizes ����������������������������������������������������������������������������������������������������������������������������������� 6 - 12mm
Maximum Drilling Depth ���������������������������������������������������������������������������������������������������������������������������������������1-1/2 in�
Maximum Drilling Height ����������������������������������������������������������������������������������������������������������������������������������1-11/16 in�
Minimum Drilling Height ������������������������������������������������������������������������������������������������������������������������������������������3/8 in�
Drill Bit Spacing ����������������������������������������������������������������������������������������������������������������������������������������������������1-1/4 in�
Fence Tilt Angle ���������������������������������������������������������������������������������������������������������������������������������������������� 0 - 90 deg�
Fence Tilt Stops ��������������������������������������������������������������������������������������������������������������������������������� 22�5, 45, 67�5 deg�
Page 2 of 2 Model T32540
Other
Number of Dust Ports ������������������������������������������������������������������������������������������������������������������������������������������������������1
Dust Port Size ������������������������������������������������������������������������������������������������������������������������������������������������������1-1/4 in�
Other Specifications:
Country Of Origin �������������������������������������������������������������������������������������������������������������������������������������������������������������� China
Warranty ��������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 1 Year
Approximate Assembly & Setup Time ���������������������������������������������������������������������������������������������������������������������� 15 Minutes
Serial Number Location ������������������������������������������������������������������������������������������������������������������������������������������������ ID Label
Sound Rating �������������������������������������������������������������������������������������������������������������������������������������������������������������88 - 90 dB
Features:
Adjustable Drilling Depth up to 1-1/2"
Clear Fence Viewing-Window for Accurate Drill Bit Placement
Removable Fence with Drilling-Height Adjustment of 3/8" – 1-11/16"
Drilling Angle of 0º – 90° with Stops at 22�5º, 45º, and 67�5º
Dust Extraction Below Drill Bits
Accessories:
(2) 8mm Drill Bits
Hex Wrench 2�5mm
Model T32540 (Mfd. Since 10/20)-6-
