Model T32720 (Mfd. Since 06/21)
-3-
Identification
Become familiar with the names and locations of the controls and features shown below to better understand
the instructions in this manual.
For Your Own Safety Read Instruction Manual Before Operating Grinder
a) Wear eye protection.
b) Use grinding wheel suitable for speed of grinder.
No list of safety guidelines can be com-
plete. Every shop environment is different.
Always consider safety first, as it applies
to your individual working conditions. Use
this and other machinery with caution and
respect. Failure to do so could result in
serious personal injury, damage to equip-
ment, or poor work results.
Like all machinery there is potential danger
when operating this machine. Accidents
are frequently caused by lack of familiarity
or failure to pay attention. Use this machine
with respect and caution to decrease the
risk of operator injury. If normal safety pre-
cautions are overlooked or ignored, seri-
ous personal injury may occur.
Tool Rest
Grinding
Wheel
Stropping
Wheel
Variable-Speed
Dial
Tool Jig
Water
Reservoir
ON/OFF Switch
w/Disabling Key
Torque
Adjustment
Knob
Tool Jig
Lock Knob
Tool Rest
Micro-Adjustment
Nut
Tool Rest
Lock Knob
(1 of 4)
Arbor
Lock Knob
