Groen Vortex 100 Series User Manual

148673 REV. G OM-VRC-3E/VRC-6E 13
D
r
a
i
n
Kit
D
iagram
OM-VRC-3E/VRC-6E
C
16
16
1
3
CUT TO
LENGTH
CUT TO
LENGTH
TO FACILITY
DRAIN
ATTACH THIS END
OF THE HOSE
143254 TO THE
UNIT INSIDE
CONDENSATE
TRAP USING THE
TENSION CLAMP.
6
6
2 " GAP MINIMUM
16
DETAIL C
SCALE 1 : 2
1
5
14
ATTACH HOSE 143254 (3/8" DIAMETER X 30"LONG) TO THIS PORT USING THE TENSION CLAMP.
16
ITEM NO.
16 14
6 5 4 3 2 1
PART NO.
143254 127523 143250 143246 140789 142550 141067 142549
DESCRIPTION HOSE 3/8" ID X 30" LONG HOSE CLAMP HOSE, LONG 3/4" ID X 10 ft. DRAIN ASSEMBLY, AUTODRAIN KIT BACK PANEL. REFERENCE ONLY. TEE, 3/4" HOSE BARB CHAMBER ASSEMBLY. REFERENCE ONLY ELBOW 3/4" HOSE BARB
