Growatt SPH4000 User Manual

Commissioning
6
Installation
5.1 Basic installation requirements
5.2 Installation requires tools and
RJ 45 terminal sequence of the
LAN line
5.3 Installation Instructions
5.4 SPH System Connection Mode
5
6.1 Commissioning of SPH
6.2 Operation modes
6.3 Country setting
6.4 Display and button
6.5 Communication
Start-up and shut
down SPH system
7
7.1 Start-up the SPH system
7.2 Disconnect the SPH system
Attention of the
installation
environment,
maintenance and
cleaning
8
Fault removal
9
11.1 Dismantling the energy storage
11.2 Packing the SPH inverter
11.3 Storing SPH inverter
11.4 Disposing of the SPH inverter
Decommissioning
Manufacturer
Warranty
11
10
Product specification
12
12.1 Growatt SPH series energy
storage machine product
specification
12.2 DC input terminal parameter
12.3 Torque
12.4 Appendix
Certificate
13
Contact
14

Growatt SPH4000 Specifications

General

Model	SPH4000
Category	Inverter
Rated Power	4000 W
Max. DC Voltage	550 V
MPPT Voltage Range	120 V - 500 V
Number of MPPTs	2
AC Output Voltage	230 V
Frequency	50/60Hz
Efficiency	97.5%
Start Voltage	150 V
Nominal DC Voltage	360V
Max. Input Current per MPPT	11 A
AC Nominal Power	4000 W
Max. AC Apparent Power	4000 VA
AC Voltage Range	180 V - 280 V
Power Factor	0.8 leading to 0.8 lagging
THDi	<3%
AC Connection Type	Single phase
Max. Charge/Discharge Power	4000 W
Nominal Battery Voltage	48 V
Communication with BMS	CAN/RS485
Operating Temperature Range	-25°C to +60°C
Protection Degree	IP65
Topology	Transformerless
Weight	25 kg
Max. PV Input Voltage	550 V
Cooling Method	Natural Convection
