Grundfos CIU 501 User Manual

English (GB)
42
11.3 Hardware setup, CIM 260 call-up connection
11.4 Hardware setup, CIU 260 call-up connection
11.5 Hardware setup, CIM 260 data connection
11.6 Hardware setup, CIU 260 data connection
Step Action
1 Install CIM 260 in the Grundfos pump according to the booster system documentation.
2 Fit an antenna to the CIM module SMA connector. See section 6.1.1 Fitting a cellular antenna.
3 Insert the SIM card in CIM 260. See section 6.1.2 Inserting the SIM card.
4 Power on the booster system.
5 Observe that LED2 turns permanently green, indicating that CIM 260 is fitted correctly. See section 6.2 LEDs
6
Observe that LED1 blinks yellow and changes to yellow pulsing after approximately 30 seconds, indicating that the cellular
network connection is working. See section 6.2 LEDs
By making a call-up from a phone, the connection can be verified. LED1 turns permanently yellow.
7
To configure CIM 260 for a call-up connection, follow the instructions in the "CIM 260 SMS commands", which you can
download from Grundfos Product Center.
8 To verify the settings after completion, you can use the SMS command "SMSSETTINGS".
CIM 260 is now ready to be accessed from a Modbus RTU master via call-up, or via SMS commands.
Step Action
1
Connect the GENIbus cable from CIU 260 to the Grundfos product. See fig. 5 in the "CIU, Communication Interface Unit
installation and operating instructions".
2 Fit an antenna to the CIM module SMA connector. See section 6.1.1 Fitting a cellular antenna.
3 Insert the SIM card in CIM 260. See section 6.1.2 Inserting the SIM card.
4 Connect the mains cable to CIU 260. See the CIU quick guide instruction, and power on CIU 260.
5 Power on the Grundfos product.
6 Observe that LED2 turns permanently green, indicating that the GENIbus connection is working. See section 6.2 LEDs.
7
Observe that LED1 blinks yellow and changes to yellow pulsing after approximately 30 seconds, indicating that the cellular
network connection is working. See section 6.2 LEDs.
By making a call-up from a phone, the connection can be verified (LED1 turns permanently yellow).
8
To configure CIU 260 for a call-up connection, follow the instructions in the "CIM 260 SMS commands" which you can
download from Grundfos Product Center.
9 To verify the settings after completion, use the SMS command "APNSETTINGS".
CIU 260 is now ready to be accessed from a Modbus RTU master via call-up, or via SMS commands.
Step Action
1 Install CIM 260 in the Grundfos product according to the product documentation.
2 Fit an antenna to the CIM module SMA connector. See section 6.1.1 Fitting a cellular antenna.
3 Insert the SIM card in CIM 260. See section 6.1.2 Inserting the SIM card.
4 Power on the Grundfos product.
5 Observe that LED2 turns permanently green. See section 6.2 LEDs.
6
Observe that LED1 blinks yellow and changes to yellow pulsing after approximately 30 seconds, indicating that the cellular
network connection is working. See section 6.2 LEDs.
7
To configure CIM 260 for a data connection, follow the instructions in the "CIM 260 SMS commands" which you can
download from Grundfos Product Center.
8
To verify the APN settings after completion, use the SMS comman
d "APNSETTINGS".
To verify that the data connection is working, use the SMS command "APNSTATUS". The connection state must be
"Context active" if ready and "Connected" if a Modbus TCP master is already communicating.
CIM 260 is now ready to be accessed from a Modbus TCP master via a data connection, or via SMS commands.
Step Action
1 Connect the GENIbus cable from CIU 260 to the Grundfos product, see the CIU quick guide instruction.
2 Fit an antenna to the CIM module SMA connector. See section 6.1.1 Fitting a cellular antenna.
3 Insert the SIM card in CIM 260. See section 6.1.2 Inserting the SIM card.
4 Connect the mains cable to CIU 260. See the CIU quick-guide instruction, and power on CIU 260.
5 Power on the Grundfos product.
6 Observe that LED2 turns permanently green, indicating that the GENIbus connection is working. See section 6.2 LEDs.
7
Observe that LED1 blinks yellow and changes to yellow pulsing after approximately 30 seconds, indicating that the cellular
network connection is working. See section 6.2 LEDs.
8
To configure CIM 260 for a data connection, follow the instructions in the "CIM 260 SMS commands", which you can
download from Grundfos Product Center.
