Grundfos CIU 501 User Manual

English (GB)
20
00103 OperationMode
A state to control the operating mode of the booster system.
0: Auto-control (setpoint control according to selected control
mode)
4: OpenLoopMin (running at minimum speed)
6: OpenLoopMax (running at maximum speed).
Note that "OnOffReq" has higher priority than the OperationMode,
meaning that you must set "OnOffReq" to "On" for the
OperationMode to have any effect.
The Hydro Multi-B can only run in auto-control mode.
The Hydro Multi-E model G can only run in auto-control mode and
OpenLoopMax.
●●- ●●●
00104 Setpoint
Sets the setpoint of the booster.
The scale is 0.01 %, so the value must be from 0 to 10000 to
represent the entire 0-100 % range.
Closed loop:
MPC, Multi-E: Percentage of closed-loop feedback sensor
maximum value.
TPED, MAGNA3-D: Percentage of the setpoint range.
Open loop:
MPC, Multi-E: Percentage of the maximum performance.
TPED, MAGNA3-D: Percentage of the nominal pump frequency.
4700: 47 %
8000: 80 %.
See section 10.3 Setpoint in closed-loop control.
●●●●●●
00105 ControlPump1
Forces the control of pump 1.
Default is auto-control.
0: Auto-control (controlled by the booster system)
2: Forced stop.
●●●- - -
00106 ControlPump2
Forces the control of pump 2.
Default is auto-control.
0: Auto-control (controlled by the booster system)
2: Forced stop.
●●●- - -
00107 ControlPump3
Forces the control of pump 3.
Default is auto-control.
0: Auto-control (controlled by the booster system)
2: Forced stop.
●●●- - -
00108 ControlPump4
Forces the control of pump 4.
Default is auto-control.
0: Auto-control (controlled by the booster system)
2: Forced stop.
●●●- - -
00109 ControlPump5
Forces the control of pump 5.
Default is auto-control.
0: Auto-control (controlled by the booster system)
2: Forced stop.
-●●-- -
00110 ControlPump6
Forces the control of pump 6.
Default is auto-control.
0: Auto-control (controlled by the booster system)
2: Forced stop.
-●●-- -
00111 SetTankFillStartLimit
Sets the start limit in tank-filling mode.
The scale is 0.01 % of tank height. See register 00215 for actual
tank height.
For tank-filling mode, see section 10.2 Tank-filling applications.
●-----
00112 SetTankFillStopLimit
Sets the stop limit in tank-filling mode.
The scale is 0.01 % of tank height.
●-----
00113 SetTankFillAlarmHighLimit
Sets the alarm high-limit in tank-filling mode.
The scale is 0.01 % of tank height.
●-----
00114 SetTankFillWarningLowLimit
Sets the warning low-limit in tank-filling mode.
The scale is 0.01 % of tank height.
●-----
Modbus
address
Register name Description
Multi-B MPC DDD Multi-E model G Multi-E/TPED model H and later
2
MAGNA3-D
