English (GB)
47
13. Modbus RTU telegram examples
Note that CRC fields are not shown in the following examples.
13.1 Modbus telegram overview
The maximum size of a Modbus RTU telegram is 256 bytes.
Telegrams must be separated by a silent interval of at least 3.5
character times.
The standard Modbus RTU telegram format is shown in the table
below.
A telegram starts with the slave address occupying one byte.
Then comes a variable-size data field. For each telegram, a CRC
is calculated and appended to the telegram, two bytes total. All
bytes in the telegram, except for the CRC itself, are included in
the check.
Note that the CRC bytes are not shown in the examples in the
following sections.
13.2 Read holding registers, 0x03
This function is used for reading holding registers from the slave.
The request telegram specifies the starting address, that is the
address of the first register to be read, and the number of holding
registers to read. In the telegram, register addresses start from
zero, meaning that registers numbered 0-16 are addressed as
0-15.
Example of request from master to slave
In the request, the slave with address 1 is asked to deliver three
contiguous registers starting from address 0x006b: 107, meaning
register 108.
Example of response from slave to master
In the response, the byte count is six since there are three
registers of two bytes. All three registers hold the value of
0x0001.
13.3 Read input registers, 0x04
This function is used for reading input registers from the slave.
Input registers are read-only registers by definition. The request
telegram specifies the starting address, that is the address of the
first register to be read, and the number of holding registers to
read. In the telegram, register addresses start from zero,
meaning that registers numbered 1-16 are addressed as 0-15.
Example of request from master to slave
In the request, the slave with address 1 is asked to deliver three
contiguous registers starting from address 0x1010: 4112,
meaning register 4113.
Example of response from slave to master
In the response, the byte count is six since there are three
registers of two bytes. All three registers hold the value of
0x2222.
13.4 Write single register, 0x06
This function is used for writing a single holding register in the
slave. The request telegram specifies the address of the register
that is to be written. Register addresses start from zero, meaning
that a register numbered 10 is addressed as 9.
The normal response is an echo of the request, indicating that the
value was written.
Example of request from master to slave
In the request, the slave with address 1 is asked to write the
value of 0xAFFE to the register at address 0x1000.
Example of response from slave to master
The response is an echo of the request.
The Modbus data model states that registers
numbered X are addressed in telegrams as X - 1, for
example register 00104 (setpoint) is addressed as
00103 in a Modbus telegram.
Slave
address
Function
code
Data CRC
1 byte 1 byte 0 to 252 bytes 2 bytes
Field Value
Address 0x01
Function code 0x03
Start address HI 0x00
Start address LO 0x6B
Quantity HI 0x00
Quantity LO 0x03
Field Value
Address 0x01
Function code 0x03
Byte count 0x06
Register 108 HI 0x00
Register 108 LO 0x01
Register 109 HI 0x00
Register 109 LO 0x01
Register 110 HI 0x00
Register 110 LO 0x01
Field Value
Address 0x01
Function code 0x04
Start address HI 0x10
Start address LO 0x10
Quantity HI 0x00
Quantity LO 0x03
Field Value
Address 0x01
Function code 0x04
Byte count 0x06
Register 4113 HI 0x22
Register 4113 LO 0x22
Register 4114 HI 0x22
Register 4114 LO 0x22
Register 4115 HI 0x22
Register 4115 LO 0x22
Field Value
Address 0x01
Function code 0x06
Address HI 0x10
Address LO 0x00
Value HI 0xAF
Value LO 0xFE
Field Value
Address 0x01
Function code 0x06
Address HI 0x10
Address LO 0x00
Value HI 0xAF
Value LO 0xFE
