Grundfos CIU 501 User Manual

English (GB)
34
9.17 Alarm simulation register block
Registers in this register block can be read by means of function codes 0x03 and/or 0x04.
Address Register name Description
Multi-B MPC DDD Multi-E model G Multi-E/TPED model H and later MAGNA3-D
00701
00702
RESERVED ------
00703 Simulation.EventCode
Code for the event (Alarm) to simulate.
See section 9.17 Alarm simulation register block.
●●● - ●●
00704 Simulation.DeviceType
Code for the device.
0: CU 351/352 controller
1: -
2: Pump
3: IO 351 pump module
4: Primary sensor
5: Redundant sensor
6: Secondary sensor
7: IO 351 I/O module
8: System
9: Analog input
10: Pilot pump
11: Limit exceeded function
12: Backup pump.
●●● - - -
00705 Simulation.DeviceNumber
Code for the device number, according to device type.
For example if Simulation.DeviceType: 2, then this register
determines the pump number [1-8].
●●● - - -
00706 Simulation.ActionType
Type of action for simulated event
0: Stop
1: Stop with delay
2: Minimum
3: User-defined
4: Maximum
5: Set pumps to local
6: No action, warning only
7: Emergency run.
-●●- - -
00707 Simulation.ResetType
0: Manual
1: Automatic.
-●●- - -
00708 Simulation.Activate
Used to activate alarm simulation with alarms and warnings.
0: Deactivate simulation
1: Activate simulation.
●●● - ●●
00709 Simulation.Active
Status of alarm simulation.
0: Alarm simulation not active
1: Alarm simulation active.
●●● - ●●
