Grundfos CIU 501 User Manual

English (GB)
39
10.9 Sensor-based Modbus registers
The tables below show the relation between the sensor-related Modbus registers and the sensor setup for the individual booster systems.
The table below shows the relationship between the
measurement modules for the Hydro Multi-E model G Modbus
and the measurement unit selected with Grundfos GO Remote for
the feedback sensor. Only one of the measurement module
groups in the table below will be available at a time.
The process feedback scaled according to ProcessFeedBackUnit
can be calculated from this formula:
Feedback (scaled) = ProcessFeedBack × (FeedBackSensorMax -
FeedBackSensorMin) / 100 % + FeedBackSensorMin
See also section 10.1 Control modes.
Hydro/Control MPC
Address Register name
FeedBack
SensorUnit
Measuring sensor, options Primary sensor, options
00301 Head 16: 0.01 m
Differential pressure, pump
(zero equals -100 m)
Differential pressure, pump
Differential pressure, Series 2000
00302 VolumeFlow 3: 0.1 m
3
/h Flow rate
Flow rate
Flow rate, Series 2000
00315 InletPressure 7: 0.001 bar Differential pressure, inlet Differential pressure, inlet
00316 RemotePressure 5: 0.001 bar
Differential pressure, external
External pressure
Differential pressure, external
External pressure
00320 RemoteTemp 18: 0.01 K Return-pipe temperature, external Return-pipe temperature, external
00337 AmbientTemp 22: 0.01 K Ambient temperature Ambient temperature
00338 InletTemp 20: 0.01 K Return-pipe temperature Return-pipe temperature
00339 OutletTemp 19: 0.01 K Flow-pipe temperature Flow-pipe temperature
00340 TemperatureDifference 21: 0.01 K Differential temperature Differential temperature
00341 OutletPressure 6: 0.001 bar
Outlet pressure
Differential pressure, outlet
Outlet pressure
Differential pressure, outlet
- - 0-100 % signal 0-100 % signal
Hydro Multi-E model G
Sensor unit configuration with the Grundfos GO Remote
Modbus data register generated from feedback sensor
measurement
bar
Head (00301)
OutletPressure (00341)
mbar
m
kPa
psi
ft
m
3
/h
VolumeFlow (00302)
m
3
/s
l/s
gpm
°C
RemoteTemperature (00316)
°F
%-
