4 | Page 5 | Page
DPC is Digital Pump Controller, which is easy to use, programmable device for
three phase pumps (DOL). It can be used to control the pumps from 1.5 to 16
Ampere.
APPLICATIONS:
DPC is very useful in water and wastewater applications, be it water transfer,
tank filling, tank emptying or even pressure boosting in Hydro-pneumatic
applications. It is ideal choice in residential, industrial or institutional segments
where water and energy conservation are of utmost importance.
PARAMETER AND SPECIFICATIONS:
Following chart shows main technical parameters & specifications:
FEATURES:
LCD screen displays pump running information
Phase loss protection (incoming as well as outgoing)
Overload protection
Motor stalled protection
Dry run protection without installing a float switch
Under voltage protection
Over voltage protection
Transient surge protection
Memory function when power off & power recovery
Visual & audio alarm for fault prompt
DIP switch settings to make it suitable for different applications like water supply,
drainage or pressure boosting
Auto/Manual switch
Liquid level probes/ floats (in case of fully automatic models) for clear water
INTRODUCTION
Main technical characteristics
Control characteristic
Level control (with probes for clear
water or with floats)
Pressure control (with pressure switch)
Working modes Manual/Auto
Main technical data
Rated output power (amperes)
1.5 to 16 A
Rated input voltage
AC 380V / 50 HZ / Three Phase
Trip response time of overload 5sec - 5min
Trip response time of pump stalled
Less than 0.5 sec
Trip response time short circuit
Less than 0.1 sec
Trip response time of under/over voltage
Less than 5 sec
Trip response time of phase loss
Less than 2 sec
Trip response time of dry run
6 sec (or this can be set manually)
Recovery time of overload
30 min
Recovery time of under/over voltage
5 min
Recovery time of dry run
30 min (or this can be set manually)
Trip voltage of over voltage
Plus 15% of rated input voltage
Trip voltage of under voltage
Minus 15% of rated input voltage
Trip current of dry run
70% of rated current
Trip current of pump stalled
200% of rated current
PROTECTIONS COVERED
DRY RUN (without float/probe)
Overload (auto calibrated or can be set)
Transient surge
Under voltage
Over voltage
Pump stalled
Short circuit
Other technical data
Permissible ambient temperature
Up to 55 Deg C
Degree of protection
IP 54
Install position
Vertical
Unit dimensions (L X W X H)
225 x 300 x 100 mm
Unit weight
3.0kg
