Grundfos MAGNA1 C User Manual

English (GB)
15
Maximum system pressure
The maximum permissible system pressure
is stated on the pump nameplate:
PN 6: 6 bar or 0.6 MPa
PN 10: 10 bar or 1.0 MPa
PN 16: 16 bar or 1.6 MPa.
Disposal
This product has been designed with focus
on the disposal and recycling of materials.
The following average disposal values apply
to all variants of MAGNA1 pumps:
• 85 % recycling
• 10 % incineration
• 5 % depositing.
This product or parts of it must be disposed
of in an environmentally sound way:
1. Use the public or private waste collection
service.
The actual inlet pressure and the
pump pressure against a closed valve
must be lower than the maximum
permissible system pressure.

Grundfos MAGNA1 C Specifications

General

Liquid temperature range	-10°C to +110°C
Maximum operating pressure	10 bar
Enclosure class	IP42
Insulation class	F
Type	Circulator pump
Pump housing	Cast iron
Series	MAGNA1
Model	MAGNA1 C
Protection Class	IP42
Approvals	CE, EAC
Connection	Flange
Power Supply	1 x 230 V, 50/60 Hz
Weight	Varies by model
