Grundfos MAGNA1 C User Manual

English (GB)
6
Type key
CodeExample (D) 40 -80 (F) (N) 220
Type range
MAGNA1
D
Single-head pump
Twin-head pump
Nominal diameter
(DN) of inlet and
outlet ports [mm]
Maximum head [dm]
F
Pipe connection
Threaded
Flange
N
Pump housing material
Cast iron
Stainless steel
Port-to-port length [mm]

Grundfos MAGNA1 C Specifications

General

Liquid temperature range	-10°C to +110°C
Maximum operating pressure	10 bar
Enclosure class	IP42
Insulation class	F
Type	Circulator pump
Pump housing	Cast iron
Series	MAGNA1
Model	MAGNA1 C
Protection Class	IP42
Approvals	CE, EAC
Connection	Flange
Power Supply	1 x 230 V, 50/60 Hz
Weight	Varies by model
